1. Imitation FIMOR scraper instruction manual
2. Degrees: 65 degrees (red) 70 degrees (milky) 75 degrees (green) 80 degrees (milky) 85 degrees (blue)
Scope of application:
Widely used in PCB, membrane switch, advertising, ceramic flower paper, etc.
Good abrasion resistance, sharp blades, easy to grind fingerprints or machine prints, different colors represent different hardnesses
Soft rubber scraper (65 degrees) can get thicker ink layer and higher coverage when printing. A thin ink layer can be obtained when printing with hard rubber (85 degrees), which is more suitable for UV ink printing with very fine fonts and lines. Try to avoid over-pressing the squeegee on the screen. This will cause the ink layer to be extremely thick, difficult to control, and excessively wear the screen. Therefore, the correct way is to make the ends of the squeegee and the edges of the screen proper. Distance and then print with appropriate pressure. When putting the squeegee into the grip, do not apply excessive pressure or use too thick a size to force the squeegee in. Instead, use the squeegee at rest rather than continuously.
Wipe off excess ink with a cloth first, and then wash with a softer cloth with a suitable solvent. Do not use strong solvents, especially ink thinner, to clean the squeegee. After grinding or before re-use, the squeegee should be allowed to stand completely to make the solvent on it completely volatilize.
It can be ground in general and general ways: belt type, roller type, knife cutting type can only grind dry squeegee. After grinding, it can not be rubbed with solvent immediately.
The squeegee should be wrapped during long-term storage and placed flat in a dry and cool room, avoiding direct light exposure, otherwise the performance and hardness of the squeegee will change.
|It is resistant to solvents, has almost no swelling, has a sharp cutting edge, and can be repeatedly ground.
||Oily ink, UV ink, printed circuit board, other high-quality printing.
|The middle layer is stiff, the outer layer is soft, the interlayer does not fall off, and the printing effect is particularly sharp.
|Abrasion resistance, good solvent resistance, can be ground and processed multiple times.
||General printing, printing and dyeing
|Good abrasion and solvent resistance
||Surface printing, various container printing
