High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Certification
Good quality Screen Printing Mesh for sales
Good quality Screen Printing Mesh for sales
I'm Online Chat Now

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

China High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier
High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier High Tension White Color 110T Polyester Printing Mesh for Touch Screen supplier

Large Image :  High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Product Details:

Place of Origin: CHINA
Brand Name: SPRING
Certification: ISO9001, FDA, ROSH, SGS
Model Number: SP-SPM Screen Printing Mesh

Payment & Shipping Terms:

Minimum Order Quantity: 1 Square meter
Price: US $0.4 - 1.4 / 1-50Meter
Packaging Details: Waterproof plastic,Bubble bag,carton,Woven bag,Packing belt.
Delivery Time: 3-5 work days
Payment Terms: L/C, , T/T, Western Union, MoneyGram
Supply Ability: 10000 Meter/Meters
Contact Now
Detailed Product Description
Material: 100% Polyester Monofilament Thickness: 100 μm 120μm 150μm
Length: 30-70m/roll Width: 0.6m-3.65m
Weave Style: Plain Woven Factory Advantage: Lowest Price, Low MOQ
Free Samples: Accepted

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

High-end production of high-density, high tension, mesh precision, high-precision touch screen printing network, applicable to 7-inch touch screen, 10.1-inch touch screen, LCD touch screen, PLC touch screen, infrared touch screen, optical touch screen, large size touch screen, electronic touch screen, display control touch screen, LCD touch screen.

The use of imported mesh yarn production screen, printing a good touch screen, no burrs, good brightness.

Can be used for capacitive touch screen printing machine, resistive touch screen printing machine, phone cover plate screen printing machine, glass lens screen printing machine ...

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Shanghai SPRING print mesh factory produced the screen printing mesh for mobile phone touch screen quality stability, the maximum tension of 35N, long service life, can be reused, the unit area can be printed theoretical value of more than 2000 times, the largest width of 3.7 meters.

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Available white or yellow plain weave touch screen:

10.1-inch touch screen,

LCD touch screen,

PLC touch screen,

Infrared touch screen,

Optical touch screen,

Large size touch screen,

Electronic touch screen,

Display control touch screen,

LCD touch screen.

High Tension White Color 110T Polyester Printing Mesh for Touch Screen
High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Best screen printing fabric for mobile phone touch screen description:

Color: yellow & white
Width: 1.1m-3.7m

Tension: 35N

Length per roll: 30m, 50m

Advantage: low elongation and high tension strength,optimize screen-printing performance.

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

High Tension Polyester Printing Screen Mesh for Electric Touch Screen Features:

With imported high quality material, We also have the most advanced testing instruments and technicians well trained by experts to guarantee a reliable quality.

High quality monofilament polyester mesh
Excellent dimensional stability, stable tension

Mesh yarn has same thickness, excellent antistatic effect, high tension and abrasion resistance.

High tension: with high breaking strength, mesh tension values are significantly higher than normal mesh.
High stability: fabric has good stability and tiny elongation,the tension in the printing process is to maintain good stability, ensure the quality of printing and the service life of web version.
High resistance to wear: adopt high quality fiber raw materials, through special processing, bolting colth surface can withstand the high pressure frequency friction, more make the fabric has high security, and resistance to seal number.
Specifications: mesh way with plain,white/yellow color mesh.

High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Polyester Printing Mesh for Touch Screen Specification
Type Mesh/cm Mesh/inch Wire Dia.(um) Mesh Opening(um) Open Area(%) Thickness(um)
DPP77/55 77 195 55 75 33 108
DPP80/48 80 203 48 77 38 77
DPP90/48 90 230 48 63 32 80
DPP100/40 100 254 40 60 36 65
DPP110/40 110 280 40 51 31 70
DPP120/40 120 305 40 43 27 75
DPP140/34 140 355 34 37 27 65

Our Factory

Shanghai SPRING is a professional manufacturer and suppliers that is concerned with the design, development and production of Cell phone touch panel printing mesh.

we have more than 30 years experience in this line since 1983. We have more than 150sets Sulzer Ruti P7100 and P7300 weaving machines to make sure the goods can be produced with good surface and high tension, we use the best quality yarn from China also imported from Japan for high count mesh.



If you are interested in any of Polyester Printing Mesh for Touch Screen or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.

Certification :
High Tension White Color 110T Polyester Printing Mesh for Touch Screen

Screen printing screens characteristic:

1. Tensile strength [g/d (g/diameter)] silk fabrics 3.7- 4.1 g/d, nylon mesh for screen printing 4.5- 5.8 g/d, polyester printing mesh 4.3- 5.5 g/d, stainless steel wire mesh 1.5 g/d.

2. Ratio of wet- and- dry strength (%), silk screen 92 ~ 100%, nylon screen mesh cloth 89-90%, polyester screen mesh 100%, monofilament screens stainless 100%.

3. Knot strength [g/d (g/diameter)], silk mesh screen 2.9 g/d, nylon screen mesh fabric 4.5-5.4 g/d, polyester fabric for screen printing 3. 4-4.4 g/d.

4. Tensile elongation (%), silk screen mesh 8 ~ 22%, nylon screenprint mesh 26 ~ 32%, polyester screenprinting fabric 16 ~ 30%, stainless steel screenprinting screens is 38%.

High Tension White Color 110T Polyester Printing Mesh for Touch Screen
