Acid and alkali resistant precision filter net 10 mesh to 600 mesh nylon silk filter
Place of Origin | Shanghai China |
---|---|
Brand Name | SPRING |
Certification | ISO9001 |
Model Number | JPP |
Minimum Order Quantity | 30M |
Price | US $ 0.5 - 15/ m |
Packaging Details | Paper tube, plastic bag, carton box, sailcloth |
Delivery Time | 2-5 Days |
Payment Terms | TT/LC/Western Union/paypal/others |
Supply Ability | 5500000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProcessing Customization | No | Material | Nylon |
---|---|---|---|
Filter Cloth Type | Monofilament Filter Cloth | Uses | Solid-liquid Separation |
Nylon mesh is also called nylon single mesh, nylon mesh,
1. Nylon mesh size 4T-240T (10 mesh - 600 mesh) nylon mesh is white
2. Wide width: 0.5m - 3.90m (with side) Conventional specifications are 115, 127, 145, 158, 165, 220, 260, 310, 340, 360, 380 (cm) and other specifications.
Wire diameter: 30um--550um
Roll length: 30-70 m / roll
Raw materials: Japanese imported silk, domestic silk.
All specifications can be customized, length and width can also be customized according to customer requirements.
Product features: high toughness, good elasticity, corrosion resistance, oil and anti-static, waterproof, acid, low temperature, high temperature, alkali resistance.
The filter mesh is made of chemical fiber such as nylon yarn, nylon yarn, polyester yarn or nanofiber, which is processed by screen mechanical processing. The nylon has the function of high temperature and alkali resistance, and the polyethylene has acid resistance. Nylon mesh is the general term for these chemical fiber woven meshes. Nylon mesh includes: (nylon blended,) nylon mesh, polyethylene mesh, shade net.
Nylon filter use: mainly used in air conditioners, purifiers, range hoods, air filters, dehumidifiers, and dust collectors, suitable for various filtration, dust removal and separation requirements, suitable for petroleum, chemical, minerals , food, pharmaceutical and other industries filter. Filters are becoming more widely used and are commonly used in homes. Millions of industrial and household appliance filters are used every day in the world. In all the filters sold, we can supply filters and finished filters.
The nylon mesh yarn produced by our company has many advantages such as strong structure, high mesh precision, good dimensional stability, good chemical resistance, good ink performance, and easy to jump.
Product details
Product display
Product specifications
100% Nylon Mesh | |||||||
Type | Weave | Mesh/CM | Mesh/inch | Wire Dia. (um) |
Mesh Opening(um) | Open Area (%) |
Thickness (um) |
PA-4/1950 | PW | 4 | 10 | 550 | 1950 | 61 | 1096 |
PA-5/1500 | PW | 5 | 13 | 500 | 1500 | 56 | 998 |
PA-6/1267 | PW | 6 | 15 | 400 | 1267 | 58 | 796 |
PA-7/1079 | PW | 7 | 18 | 350 | 1079 | 57 | 691 |
PA-8/900 | PW | 8 | 20 | 350 | 900 | 52 | 697 |
PA-9/861 | PW | 9 | 24 | 250 | 861 | 60 | 492 |
PA-10/750 | PW | 10 | 25 | 250 | 750 | 56 | 494 |
PA-12/533 | PW | 12 | 30 | 300 | 533 | 41 | 590 |
PA-14/514 | PW | 14 | 35 | 200 | 514 | 52 | 391 |
PA-16/425 | PW | 16 | 40 | 200 | 425 | 46 | 393 |
PA-18/356 | PW | 18 | 45 | 200 | 356 | 41 | 395 |
PA-20/300 | PW | 20 | 50 | 200 | 300 | 36 | 396 |
PA-24/267 | PW | 24 | 60 | 150 | 267 | 41 | 292 |
PA-28/207 | PW | 28 | 70 | 150 | 207 | 34 | 295 |
PA-30/213 | PW | 30 | 76 | 120 | 213 | 41 | 230 |
PA-32/213 | PW | 32 | 80 | 100 | 213 | 46 | 186 |
PA-36/178 | PW | 36 | 90 | 100 | 178 | 41 | 189 |
PA-40/150 | PW | 40 | 100 | 100 | 150 | 36 | 192 |
PA-44/127 | PW | 44 | 110 | 100 | 127 | 31 | 195 |
PA-48/128 | PW | 48 | 120 | 80 | 128 | 38 | 150 |
PA-56/119 | PW | 56 | 142 | 60 | 119 | 44 | 96 |
PA-59/109 | PW | 59 | 150 | 60 | 109 | 42 | 110 |
PA-64/96 | PW | 64 | 163 | 60 | 96 | 38 | 116 |
PA-72/89 | PW | 72 | 183 | 50 | 89 | 41 | 90 |
PA-80/75 | PW | 80 | 203 | 50 | 75 | 36 | 93 |
PA-88/71 | PW | 88 | 224 | 43 | 71 | 39 | 70 |
PA-96/61 | PW | 96 | 244 | 43 | 61 | 34 | 74 |
PA-100/57 | PW | 100 | 254 | 43 | 57 | 32 | 75 |
PA-104/53 | PW | 104 | 264 | 43 | 53 | 31 | 76 |
PA-110/48 | PW | 110 | 280 | 43 | 48 | 28 | 78 |
PA-120/40 | PW | 120 | 305 | 43 | 40 | 23 | 80 |
PA-130/34 | PW | 130 | 330 | 43 | 34 | 19 | 83 |
PA-140/33 | PW | 140 | 355 | 38 | 33 | 22 | 73 |
PA-150/28 | TW | 150 | 380 | 39 | 28 | 17 | 75 |
PA-157/25 | TW | 157 | 400 | 39 | 25 | 15 | 76 |
PA-165/30 | TW | 165 | 420 | 30 | 30 | 25 | 54 |
PA-200/21 | TW | 200 | 500 | 30 | 21 | 17 | 56 |
PA-240/3 | TW | 240 | 600 | 39 | 3 | 0.5 | 68 |
