Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees

  • Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees
  • Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees
  • Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees
  • Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees
Place of Origin ShangHai
Brand Name SPRING
Certification ISO9001
Model Number DPP
Minimum Order Quantity 30M
Price www.silkscreenmesh.com
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 2-5 Days
Payment Terms TT/LC/Western Union/paypal/others
Supply Ability 5500000m/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Polyester Weaving Method Plain Weave
Width 0.6-3.9m Mesh 10-165T / Cm
Wire Diameter 550-31 Microns Open Hole 1500-25 Microns
Thickness 0.045-1.5mm
Leave a Message
Product Description

Wear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees





Main products: nylon mesh yarn, polyester mesh yarn, silk screen mesh yarn, filter mesh yarn, etc., polyester dust net, PET dust net, nylon dust net, nylon sieve, polyester sieve, etc.

Polyester mesh, nylon mesh, flour mesh, stainless steel mesh, metal mesh, filter mesh and related products.
Material Polyester (DPP), Nylon (JPP) Polyethylene (PE), Polypropylene (PP) Polyester, PET.
The color is white black yellow orange. customizable

Equipment: more than 200 Swiss Sulzer loom, 2 Beninger warping machines, 2 water washing and setting machines, weaving machine width: 280cm, 330cm, 360cm, 390cm. Exports: USA, Germany, Japan, UK, Italy, Russia, Brazil, Turkey, Argentina, Pakistan, Thailand, Singapore, South Korea, Mexico and other parts of the world.

The company produces polyester printing nets, which are widely used in printing, in the electronics industry, PCB silk chemical fiber, ceramic printing, printed circuit boards, printed plate making, sign advertising, flower paper, filtration, luggage, environmental protection and other industries.

Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 0Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 1Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 2Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 3Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 4Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 5Printing screen Polyester meshWear-resistant high-tension screen 50 mesh wire diameter 0.15 high temperature 200 degrees 6
100% Polyester Monofilament Mesh
Type Mesh/CM Mesh/inch Wire Dia.
(um)		 Mesh Opening(um) Open Area
(%)		 Thickness
(um)
DPP7/350 7 18 350 1080 57 640
DPP8/300 8 20 300 950 58 550
DPP10/200 10 25 200 800 64 380
DPP10/250 10 25 250 750 56 480
DPP12/200 12 30 200 633 58 390
DPP12/250 12 30 250 583 49 480
DPP16/200 16 40 200 425 46 400
DPP20/80 20 50 80 420 71 140
DPP20/100 20 50 100 400 64 185
DPP20/120 20 50 120 380 58 230
DPP20/150 20 50 150 350 49 290
DPP24/80 24 60 80 337 65 150
DPP24/100 24 60 100 317 58 190
DPP24/120 24 60 120 297 51 235
DPP24/150 24 60 150 267 41 295
DPP29/120 29 74 120 225 43 238
DPP32/64 32 80 64 249 63 115
DPP32/80 32 80 80 233 55 150
DPP32/100 32 80 100 213 46 180
DPP34/100 34 86 100 194 44 185
DPP36/100 36 90 100 178 41 190
DPP39/55 39 99 55 201 62 90
DPP39/80 39 99 80 176 47 150
DPP39/100 39 99 100 156 37 195
DPP43/80 43 110 80 153 43 155
DPP47/55 47 120 55 158 55 95
DPP47/71 47 120 71 142 44 130
DPP53/55 53 135 55 134 50 98
DPP53/64 53 135 64 125 44 115
DPP53/71 53 135 71 118 39 133
DPP59/55 59 150 55 114 46 100
DPP59/64 59 150 64 105 39 118
DPP64/55 64 163 55 101 42 102
DPP64/64 64 163 64 92 35 120
DPP72/48 72 183 48 91 43 75
DPP72/55 72 183 55 84 37 105
DPP77/55 77 195 55 75 33 108
DPP80/48 80 203 48 77 38 77
DPP90/48 90 230 48 63 32 80
DPP100/40 100 254 40 60 36 65
DPP110/40 110 280 40 51 31 70
DPP120/34 120 305 34 48 35 63
DPP120/40 120 305 40 43 27 75
DPP140/34 140 355 34 37 27 65
DPP150/31 150 380 31 36 29 52
DPP150/34 150 380 34 33 24 56
DPP165/27 165 420 27 34 31 50
DPP165/31 165 420 31 30 24 58
