Soymilk nylon filter screen nylon filter coffee filter 80 mesh-600 mesh wide up to 3.7M
| Place of Origin | Shanghai |
|---|---|
| Brand Name | SPRING |
| Certification | ISO9001 |
| Model Number | JPP |
| Minimum Order Quantity | 30M |
| Price | www.silkscreenmesh.com |
| Packaging Details | Paper tube, plastic bag, carton box, sailcloth |
| Delivery Time | 2-5 Days |
| Payment Terms | TT/LC/Western Union/paypal/others |
| Supply Ability | 5500000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Nylon | Type | Efficient |
|---|---|---|---|
| Use | Oil-water Separation | Applicable | Object: Air |
| Opening Rate | 90 (%) | Weave Pattern | Plain Weave |
| Monofilament Diameter | 1 (mm) | Mesh | 200 (mesh / Inch) |
| Radial Breaking Strength | 1 (N / Cm) | Wide | 1 (m) |
| Density | 1 (root / 10cm) |
Product Description
Nylon mesh is also called nylon blend. The material is food-grade nylon 66, which is non-toxic and odorless. High strength, large elongation and excellent elasticity. Strong and abrasion-resistant, ranking first among all fibers. High temperature resistance, high temperature resistance, oil resistance, corrosion resistance, strong alkali and weak acid resistance, stable chemical properties. Good electrical insulation, anti-vibration and sound absorption, and has certain flame resistance. Nylon mesh is fine and transparent. It is widely used as sieve filter in marine aquaculture, flour processing, nylon screen printing, pharmaceutical, chemical, dye, monosodium glutamate, fishery, food and other industries.
[Nylon mesh use]: liquid filtration, powder filtration, petroleum, mining, pharmaceutical, chemical plant, paint, ink, oil product filtration, alcohol filtration, paint filtration, dye filtration, resin, monosodium glutamate, fishery, impurity filtration, food It is widely used in industrial screens and filtration. You are welcome to wholesale, retail, large quantity favorably! !! !!
[Characteristics of nylon mesh]: non-toxic, odorless, tasteless, high strength, large elongation, excellent elasticity. It has the characteristics of high toughness, good elasticity, weak acid resistance, oil resistance, alkali resistance, abrasion resistance, temperature resistance, etc. It also has good insulation properties and low lubrication coefficient. Its application range is very wide.
Shanghai Yuchunyuan Industrial Co., Ltd. has a history of production, processing and sales of various screens, filter cloths, filter bags, filters, filters, net cloths, mesh yarns and related products. Has provided high-quality products to more than 500 well-known pharmaceutical, chemical, new materials, environmental protection, petroleum, printing, automotive, mining, metallurgy, electronics, electrical, high-tech and other enterprises.
The main purpose of the product: dustproof of the earpiece, textile printing and dyeing, electronic printing, circuit board printing, ceramics, glass, arts and crafts, food tableware, medical, chemical filtration and other industries.
This product has passed SGS environmental protection certification and FDA food grade certification, and has the characteristics of high temperature resistance, acid and alkali resistance, wear resistance, non-toxic and food grade.
| 100% Nylon Mesh | |||||||
| Type | Weave | Mesh/CM | Mesh/inch | Wire Dia. (um) |
Mesh Opening(um) | Open Area (%) |
Thickness (um) |
| PA-4/1950 | PW | 4 | 10 | 550 | 1950 | 61 | 1096 |
| PA-5/1500 | PW | 5 | 13 | 500 | 1500 | 56 | 998 |
| PA-6/1267 | PW | 6 | 15 | 400 | 1267 | 58 | 796 |
| PA-7/1079 | PW | 7 | 18 | 350 | 1079 | 57 | 691 |
| PA-8/900 | PW | 8 | 20 | 350 | 900 | 52 | 697 |
| PA-9/861 | PW | 9 | 24 | 250 | 861 | 60 | 492 |
| PA-10/750 | PW | 10 | 25 | 250 | 750 | 56 | 494 |
| PA-12/533 | PW | 12 | 30 | 300 | 533 | 41 | 590 |
| PA-14/514 | PW | 14 | 35 | 200 | 514 | 52 | 391 |
| PA-16/425 | PW | 16 | 40 | 200 | 425 | 46 | 393 |
| PA-18/356 | PW | 18 | 45 | 200 | 356 | 41 | 395 |
| PA-20/300 | PW | 20 | 50 | 200 | 300 | 36 | 396 |
| PA-24/267 | PW | 24 | 60 | 150 | 267 | 41 | 292 |
| PA-28/207 | PW | 28 | 70 | 150 | 207 | 34 | 295 |
| PA-30/213 | PW | 30 | 76 | 120 | 213 | 41 | 230 |
| PA-32/213 | PW | 32 | 80 | 100 | 213 | 46 | 186 |
| PA-36/178 | PW | 36 | 90 | 100 | 178 | 41 | 189 |
| PA-40/150 | PW | 40 | 100 | 100 | 150 | 36 | 192 |
| PA-44/127 | PW | 44 | 110 | 100 | 127 | 31 | 195 |
| PA-48/128 | PW | 48 | 120 | 80 | 128 | 38 | 150 |
| PA-56/119 | PW | 56 | 142 | 60 | 119 | 44 | 96 |
| PA-59/109 | PW | 59 | 150 | 60 | 109 | 42 | 110 |
| PA-64/96 | PW | 64 | 163 | 60 | 96 | 38 | 116 |
| PA-72/89 | PW | 72 | 183 | 50 | 89 | 41 | 90 |
| PA-80/75 | PW | 80 | 203 | 50 | 75 | 36 | 93 |
| PA-88/71 | PW | 88 | 224 | 43 | 71 | 39 | 70 |
| PA-96/61 | PW | 96 | 244 | 43 | 61 | 34 | 74 |
| PA-100/57 | PW | 100 | 254 | 43 | 57 | 32 | 75 |
| PA-104/53 | PW | 104 | 264 | 43 | 53 | 31 | 76 |
| PA-110/48 | PW | 110 | 280 | 43 | 48 | 28 | 78 |
| PA-120/40 | PW | 120 | 305 | 43 | 40 | 23 | 80 |
| PA-130/34 | PW | 130 | 330 | 43 | 34 | 19 | 83 |
| PA-140/33 | PW | 140 | 355 | 38 | 33 | 22 | 73 |
| PA-150/28 | TW | 150 | 380 | 39 | 28 | 17 | 75 |
| PA-157/25 | TW | 157 | 400 | 39 | 25 | 15 | 76 |
| PA-165/30 | TW | 165 | 420 | 30 | 30 | 25 | 54 |
| PA-200/21 | TW | 200 | 500 | 30 | 21 | 17 | 56 |
| PA-240/3 | TW | 240 | 600 | 39 | 3 | 0.5 | 68 |
