150 Micron Nylon Mesh

Place of Origin Shanghai China
Brand Name SPRING
Certification ISO9001
Model Number JPP
Minimum Order Quantity 30m
Price www.springscreenmesh.com
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 3-5 Days
Payment Terms L/C, T/T, D/P, Western Union, Paypal, Money Gram
Supply Ability 500000m/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Materil Nylon Width 0.1m-3.7m
Weave Type Plain Elasticity Low
Mesh Count 10mesh-350mesh Roll Length 30-70 M/roll
Free Sample Accepted Usage Liquid Filter
Type Filter Elements Hole Shape Square
HS Code 5911200090
Leave a Message
Product Description

150 Micron Nylon Mesh

150 Micron Nylon Mesh is produced by 100% Nylon yarn, it is widely used for filtration, such as air or liquid or solid or power filter.and used in high-density printed circuit boards,textile printing and dyeing, printing plate, electronic printing, ceramics, glass printing, the industries of petroleum, chemical, metallurgy, cement, environmental dedusting. and adadvertisement signpost making etc...

SPRING nylon monofilament mesh, is well-suited for printing onto curved or rigid surfaces because of its flexibility and elasticity. In addition, its reliable mechanical resistance and good emulsion adhesion make it suitable for printing with abrasive paste or substrate.



150 Micron Nylon Mesh Specifications:

*Material: 100% nylon (polyester available if needed)

*Weaving: Plain weave (Twill weave available if needed)

*Mesh Count: 4T~140T mesh/cm(11mesh~355 mesh/inch)

*Max. Width: 365cm (143 inch)

*Color: White/yellow/black



150 Micron Nylon Mesh Features & advantages:

*Stable Tension

*Efficient production

*Long working life

*Even opening and Standard size

*High tension and Low elongation

*Acid resistance and Alkali resistance

*Best price, High quality & Excellent service



150 Micron Nylon Mesh Application:

SPRING provide nylon filter mesh for liquid filtration, separation and sifting, with special-made processing machines and equipment, SPRING is capable of heat-slitting mesh into mesh ribbons without fraying edges.It is widely used in filteration (wather,flour, juices. soybean milk, oil,tea,cheese, air purification, power coating filtering in industry etc. )

nylon xxx series sieve mesh is what we are producing now in a wide range of mesh counts, and our products offer significant advantages over the traditional monofilament polyester
Faster tensioning without damage to the threads;
Improved fabric strength;
Faster tension stabilization;
Higher tension threshold and breaking point;
Less tension loss during the stretching process;
Faster turnaround time from the screen room to the pressroom;
Improved registration due to stable tension;
Application of Nylon sieve cloth
Nylon Sieve Mesh for flour or other granule widly used in industrial filter,oil,chemical,printing and other products,the specification is complete,special specification can be customized.



Main specification as follow:

Opening size: From 30 micron to 2000 micron
Material: PA6(Nylon), PA66(food grade), Polyester
Width range from: 0.6m-3.68m
Characters: the mesh with great precision exact and regular square holes, food grade, very good dimensional stability and no any chemicals treatment in the production process
Applications: nylon mesh is avaliable in standard and food grade for food, chemicals, medical and automotive paint applications.



Material :manufactured by nylon monofilament yarns
Opening :the mesh with great precision exact and regular square holes
Chemicals :no unwanted chemicals,no any chemicals treatment in the production process
Safe Grade :very safe,very thin,food grade
Shape :can made by disc,tube,piece,roll any sizes and shape,max roll length1000m
Temperature :use temperature under 120℃
Dimensoinal :very good dimensional stability

We can provide products in special specifications according to your demand.



Contact Us:

Sales Maganer: Sara

Tel: 0086-21-56011358
Fax: 0086-21-56011358
Mob: 0086-18117348869
E-mail: info@silkscreenmesh.com
Web:
http://www.silk-screen-mesh.com
http://www.springscreenmesh.com
Skype: springmesh
Twitter: @springmesh
Wechat/whatsapp:008618117348869
Yahoo: springmesh@yahoo.com
Gmail: springscreenmesh@gmail.com
Facebook: https://www.facebook.com/pages/Spring-Industrial-Corporation/373192469453725

150 Micron Nylon Mesh 0150 Micron Nylon Mesh 1150 Micron Nylon Mesh 2

Nylon Mesh
Type

Mesh Count

(/cm)

Mesh Count

(/inch)

Thread Diameter

(/um)

Mesh Opening

(um)

Open Area

(%)

Thickness

(um)

JPP 4 4 10 550 1950 61 1020
JPP 5 5 13 400 1600 64 760
JPP 5 5 13 500 1500 56 940
JPP 6 6 15 350 1317 62 680
JPP 6 6 15 400 1267 58 780
JPP 7 7 18 350 1079 57 675
JPP 8 8 20 300 950 58 585
JPP 8 8 20 350 900 52 685
JPP 9 9 24 250 861 60 465
JPP 10 10 25 300 700 49 576
JPP 12 12 30 250 583 49 470
JPP 12 12 30 300 533 41 585
JPP 14 14 35 200 514 52 375
JPP 16 16 40 200 425 46 380
JPP 18 18 45 200 356 41 385
JPP 20 20 50 150 350 49 375
JPP 20 20 50 200 300 36 385
JPP 24 24 60 150 267 41 285
JPP 28 28 70 120 237 44 215
JPP 30 30 76 120 213 41 225
JPP 32 32 80 100 213 46 170
JPP 36 36 90 100 178 41 180
JPP 40 40 100 100 150 36 190
JPP 43 43 110 80 153 43 135
JPP 48 48 120 80 128 38 145
JPP 56 56 142 60 119 44 96
JPP 59 59 150 60 109 42 102
JPP 64 64 163 60 96 38 108
JPP 72 72 183 50 89 41 88
JPP 80 80 203 50 75 36 92
JPP 90 90 230 43 68 38 70
JPP 100 100 254 43 57 32 72
JPP 110 110 280 43 48 28 76
JPP 120 120 305 43 40 23 78
JPP 130 130 330 43 34 19 80
JPP 140 140 355 38 33 22 75
