Mesh Material/Shirt Printing

Place of Origin China
Brand Name SPRING
Certification ISO9001;ISO14001
Model Number DPP
Minimum Order Quantity 30m
Price www.springscreenmesh.com
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 3-5 Days
Payment Terms TT/LC/Western Union/paypal/others
Supply Ability 5000000m/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Mesh Count 7-180T Material 100% Polyester
Weave Type Plain Elasticity Low
Printing Polyester Screen Printing Monofilament Style Yes
Leave a Message
Product Description

Mesh Material/Shirt Printing

http://www.springscreenmesh.com

Mesh Material/Shirt Printing Specifications:

*Material: 100% polyester (Nylon available upon request)

*Weaving: Plain weave (Twill weave available upon request)

*Specs: 7T~180T mesh/cm (18mesh/inch~420mesh/inch)

*Max. Width: 375cm (147")

*Color: White and yellow (available upon request)

We can provide products in special specifications according to your demand.



Mesh Material/Shirt Printing Features & advantages:

*Long working life

*Even opening and Standard size

*High tension and Low elongation

*Acid resistance and Alkali resistance

*Faster turnaround time from the screen room to the pressroom

Mesh Material/Shirt Printing Benefits:

1.Ready to use: the degreasing pre-treatment can be eliminated.

2.Superior stencil adhesion, resulting in less stencil breakdown on press, delivering longer print runs far beyond other conventional treated fabrics.Better resolution of fine details.

3.Improved wettability and optimum stencil surface.

4.Safe under exposure with all emulsion types,Photopolymer,Dual-Cure,Diazo and Capillary Films.

5.Holds finer details with no compromise in stencil durability.

6.Good mechanical behavior.

7.Friendly use.

8.Helps reduce ghost imaging.

9.Good anti-sttic properties.

Mesh Material/Shirt Printing Applications:

Widely used in T-Shirt printing, printing LED and LCD, graphic screen printing, package printing, filtering, textile printing and dyeing, printing plate, printed electronics, ceramic decorating, glass printing, printing solar cell(battery), printing circuitry board ,CD/DVD printing and other industries.

Contact Us:

Sales Maganer: Sara

E-mail: info@silkscreenmesh.com

Skype: springmesh

MSN: springmesh@live.com

Yahoo: springmesh@yahoo.com

Gmail: springscreenmesh@gmail.com

Website: www.springscreenmesh.com

Mob: 86-15721376592

Mesh Material/Shirt Printing 0

Mesh Material/Shirt Printing 1

Mesh Material/Shirt Printing 2

Mesh Material/Shirt Printing 3




Specifications:

Type

Mesh/CM

Mesh/inch

Wire Dia.(um)

Mesh Opening(um)

Open Area
(%)

Thickness

(um)

DPP7/350

7

18

350

1080

57

640

DPP8/300

8

20

300

950

58

550

DPP10/250

10

25

250

700

49

620

DPP12/250

12

30

250

583

49

450

DPP16/200

16

40

200

425

46

400

DPP20/100

20

50

100

400

64

200

DPP20/180

20

50

180

320

41

350

DPP24/100

24

60

100

317

58

190

DPP24/120

24

60

120

297

51

240

DPP29/120

29

76

120

213

41

240

DPP32/80

32

80

80

232

55

140

DPP32/100

32

80

100

213

46

200

DPP34/100

34

86

100

194

44

221

DPP36/80

36

90

80

198

51

156

DPP36/100

36

90

100

178

41

216

DPP39/55

39

99

55

201

62

100

DPP40/80

40

100

80

170

46

150

DPP43/80

43

110

80

153

43

130

DPP47/55

47

120

55

158

55

105

DPP47/71

47

120

71

142

44

135

DPP53/55

53

135

55

134

50

105

DPP53/64

53

135

64

125

44

120

DPP59/55

59

150

55

114

46

105

DPP59/64

59

150

64

105

39

120

DPP61/55

61

155

55

109

44

110

DPP62/64

62

155

64

100

37

115

DPP64/55

64

163

55

101

42

105

DPP64/64

64

163

64

92

35

120

DPP68/55

68

173

55

92

39

107

DPP68/64

68

173

64

83

32

130

DPP72/48

72

183

48

94

46

80

DPP72/55

72

183

55

84

37

100

DPP77/55

77

195

55

75

33

105

DPP80/48

80

200

48

77

38

92

DPP90/45

90

230

45

72

42

70

DPP90/48

90

230

48

66

35

85

DPP100/40

100

250

40

61

37

70

DPP110/40

110

280

40

52

33

85

DPP120/34

120

300

34

48

32

55

DPP120/40

120

300

40

42

26

68

DPP140/34

140

350

34

37

24

58

DPP150/31

150

380

31

34

26

46

DPP165/31

165

420

31

30

24

60

DPP180/27

180

460

27

29

27

54
