316L stainless steel wire filter mesh
Place of Origin | Shanghai China |
---|---|
Brand Name | SPRING |
Certification | ISO9001 |
Model Number | 160/1400 |
Minimum Order Quantity | 30m |
Price | www.springscreenmesh.com |
Packaging Details | Paper tube, plastic bag, carton box, sailcloth |
Delivery Time | 3-5 Days |
Payment Terms | TT/LC/Western Union/paypal/others |
Supply Ability | 10000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xFilter Rating | 75%-99% | Thickness | 0.1mm |
---|---|---|---|
Length | 30m-70m | Width | 0.6-3.65m |
Usage | Liquid Filter | Type | Filter Cylinder |
Material | 316L | Hole Shape | Square |
Specifications
stainless steel wire mesh filter mesh
ISO9001 ISO14001
302/304/304L/316/314/316L
can be cut into pieces or bag
Stainless Steel Filter Mesh
Application
Filter mesh for gas and liquid serves well in filtering and deleting the particle mixture in foam, liquid and air, by way of distillation, absorbing, evaporating and filtering process, in petroleum, chemicals, metallurgy, machine, pharmaceuticals, automobile and environmental protection.
Specification
- Material: 302/304/304L/310/316/314
- Weaving: Plain weaving, twill weaving, microgroove-plain weaving, stain weaving, formatted with a lot of burs
- Mesh Count: 160~500 mesh
- Length: 1~500m
- Width: 914~1600mm (some products can reach a width of 4000mm )
- Can be cut into coils and pieces according to customers’ requirements
Stainless steel wire can be substituted by copper, galvanized iron wire polyamide fiber or F46 wire if need.
Mesh |
Wire Dia(mm) |
Opening(mm) |
Material(AISI) |
2mesh*2mesh |
1.8 |
10.9 |
304 or 316 |
3mesh*3mesh |
1.5 |
6.96 |
304 or 316 |
4mesh*4mesh |
1 |
5.35 |
304 or 316 |
7mesh*7mesh |
1 |
2.63 |
304 or 316 |
10mesh*10mesh |
0.6 |
1.94 |
304 or 316 |
12mesh*12mesh |
0.5 |
1.62 |
304 or 316 |
16mesh*16mesh |
0.4 |
1.19 |
304 or 316 |
16mesh*16mesh |
0.35 |
1.24 |
304 or 316 |
18mesh*18mesh |
0.35 |
1.06 |
304 or 316 |
20mesh*20mesh |
0.4 |
0.87 |
304 or 316 |
24mesh*24mesh |
0.26 |
0.8 |
304 or 316 |
30mesh*30mesh |
0.3 |
0.55 |
304 or 316 |
35mesh*35mesh |
0.17 |
0.56 |
304 or 316 |
40mesh*40mesh |
0.23 |
0.4 |
304 or 316 |
50mesh*50mesh |
0.2 |
0.31 |
304 or 316 |
60mesh*60mesh |
0.15 |
0.27 |
304 or 316 |
70mesh*70mesh |
0.12 |
0.24 |
304 or 316 |
80mesh*80mesh |
0.13 |
0.19 |
304 or 316 |
90mesh*90mesh |
0.1 |
0.16 |
304 or 316 |
100mesh*100mesh |
0.09 |
0.15 |
304 or 316 |
120mesh*120mesh |
0.063 |
0.12 |
304 or 316 |
150mesh*150mesh |
0.053 |
0.11 |
304 or 316 |
180mesh*180mesh |
0.053 |
0.09 |
304 or 316 |
200mesh*200mesh |
0.04 |
0.07 |
304 or 316 |
250mesh*250mesh |
0.04 |
0.063 |
316 |
300mesh*300mesh |
0.04 |
0.044 |
316 |
325mesh*325mesh |
0.035 |
0.043 |
316L |
350mesh*350mesh |
0.03 |
0.042 |
316L |
400mesh*400mesh |
0.03 |
0.33 |
316L |
450mesh*450mesh |
0.028 |
0.028 |
316L |
500mesh*500mesh |
0.025 |
0.026 |
316L |
