PET waterproof & antistatic monofialment polyester audio devices filter mesh fabric

Place of Origin Shanghai China
Brand Name SPRING
Certification ISO9001
Model Number DPP
Minimum Order Quantity 30m
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 3-5 Days
Payment Terms TT/LC/Western Union/paypal/others
Supply Ability 5500000m/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Filter Rating 99% Thickness 0.1mm
Length 30m-70m Width 0.6-3.65m
Usage Liquid Filter Type Filter Cylinder
Material Polyester Hole Shape Square
Leave a Message
Product Description


monofilament polyester audio device filter mesh fabric
waterproof -antistatic-shrink resistance
can cut into different shape

Filter Products For Audio Devices

1.General introduction:
SPRING has established a new benchmark for the acoustics industry for the protection of loudspeakers and microphones.Highest particle instruction at lowest values(thin fiber and optimized mesh opening). Our Perforated Metal is also called speaker mesh,is widely used in high-grade sound box,the core filter and so on;As well as our black polyester mesh often used as dust screen cloth for speaker box.
2. Features

  1. Clearly defined acoustic impedance clusters
  2. Minimized particle intrusion
  3. Efficient and economic production facilities
  4. Full environmental certification and approval
  5. Halogen-free dyestuff and hydrophobic coating
  6. Thinnest available yarn
  7. Unlimited colors

3. Specifications:

Polyester Printing Mesh
ModelSpecification   (/cm)Mesh count (mesh/inch)Thread Diameter     (um)Mesh opening(um)Open Area(%)Thickness(um)Theoretic Ink Volume (cm3/m2)
PET36/178369090178 44 153 67
PEt39/183399964183 54 109 59
PET39/176399971176 50 121 61
PET43/1454311080145 41 136 56
PET47/1414712064141 47 109 51
PET100/511002544051 30 85 26
PET110/431102804043 26 68 18
PET120/411203053541 23 60 14
PET130/361303303436 24 58 14
PET140/321403503432 19 58 11
PET150/311503803031 23 51 12
PET165/251654203125 16 53 8
Remark:The above datas are theoretic ,please reference the actual datas if there it differs.
