350 micron filter mesh(20T/150um)
| Place of Origin | Shanghai China |
|---|---|
| Brand Name | SPRING |
| Certification | ISO9001 |
| Model Number | JPP |
| Minimum Order Quantity | 30m |
| Price | 1-22$/m |
| Packaging Details | Paper tube, plastic bag, carton box, sailcloth or according to the customer's special requests |
| Delivery Time | 3-5 Days |
| Payment Terms | L/C, T/T, Western Union, Paypal |
| Supply Ability | 50000000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Filter Rating | 70-99% | Thickness | 0.08mm |
|---|---|---|---|
| Length | 30-70m | Width | 60cm-365cm |
| Usage | Liquid Filter | Type | Filter Elements |
| Material | Nylon | Hole Shape | Square |
Product Description
Specifications
micron filter mesh
1.Even opening,smooth surface
2.High tensive low elongation
3.Plain weave:13-380mesh/inch
4.ISO9001;SGS
350 micron filter mesh(20T/150um)
100% nylon monofilament filter mesh
Product Description:
1.Material: 100% nylon (polyester available if needed)
2.Weaving: Plain weave (Twill weave available if needed)
3.Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)
4.Max. width: 365cm (143inch)
5.Color: white/yellow/black
6.Monofilament or Doublefilament
7.We can provide products in special specifications according to your demand.
Specifications
micron filter mesh
1.Even opening,smooth surface
2.High tensive low elongation
3.Plain weave:13-380mesh/inch
4.ISO9001;SGS
350 micron filter mesh(20T/150um)
100% nylon monofilament filter mesh
Product Description:
1.Material: 100% nylon (polyester available if needed)
2.Weaving: Plain weave (Twill weave available if needed)
3.Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)
4.Max. width: 365cm (143inch)
5.Color: white/yellow/black
6.Monofilament or Doublefilament
7.We can provide products in special specifications according to your demand.
Features & advantages:
1. Faster turnaround time from the screen room to the pressroom
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Imported weaving machines from Switzerland and Italy
Specifications:
| Nylon Filter Mesh | |||||||
| Model |
mesh count (/cm) |
mesh count (/inch) |
thread diameter (um) |
mesh opening (um) |
open area (%) |
thickness (um) |
weight ( g/ m2 ) |
| NL4/1931 | 4 | 10 | 550 | 1931 | 60 | 1100 | 251 |
| NL5/1485 | 5 | 13 | 500 | 1485 | 55 | 1000 | 270 |
| NL5/1535 | 5 | 13 | 450 | 1535 | 59 | 900 | 218 |
| NL6/1254 | 6 | 15 | 400 | 1254 | 57 | 800 | 199 |
| NL7/1068 | 7 | 18 | 350 | 1068 | 56 | 700 | 183 |
| NL8/891 | 8 | 20 | 350 | 891 | 51 | 700 | 203 |
| NL8/990 | 8 | 20 | 250 | 990 | 63 | 500 | 104 |
| NL9/853 | 9 | 24 | 250 | 853 | 59 | 500 | 125 |
| NL10/743 | 10 | 25 | 250 | 743 | 55 | 500 | 130 |
| NL10/693 | 10 | 25 | 300 | 693 | 48 | 600 | 187 |
| NL12/578 | 12 | 30 | 250 | 578 | 48 | 500 | 156 |
| NL12/528 | 12 | 30 | 300 | 528 | 40 | 600 | 224 |
| NL14/410 | 14 | 35 | 300 | 410 | 33 | 510 | 261 |
| NL14/509 | 14 | 35 | 200 | 509 | 51 | 340 | 116 |
| NL16/421 | 16 | 41 | 200 | 421 | 45 | 340 | 136 |
| NL16/371 | 16 | 41 | 250 | 371 | 35 | 425 | 213 |
| NL17/384 | 17 | 42 | 200 | 384 | 43 | 340 | 139 |
| NL18/332 | 18 | 45 | 220 | 332 | 36 | 374 | 181 |
| NL20/347 | 20 | 50 | 150 | 347 | 48 | 255 | 93 |
| NL20/297 | 20 | 50 | 200 | 297 | 35 | 340 | 166 |
| NL24/264 | 24 | 60 | 150 | 264 | 40 | 255 | 112 |
| NL28/235 | 28 | 70 | 120 | 235 | 43 | 204 | 84 |
| NL28/205 | 28 | 70 | 150 | 205 | 33 | 255 | 131 |
| NL30/211 | 30 | 76 | 120 | 211 | 40 | 204 | 91 |
| NL32/210 | 32 | 80 | 100 | 210 | 45 | 170 | 66 |
| NL36/176 | 36 | 90 | 100 | 176 | 40 | 170 | 75 |
| NL40/149 | 40 | 100 | 100 | 149 | 35 | 170 | 83 |
| NL44/126 | 44 | 110 | 100 | 126 | 31 | 170 | 91 |
| NL43/151 | 43 | 110 | 80 | 151 | 42 | 136 | 58 |
| NL48/127 | 48 | 120 | 80 | 127 | 37 | 136 | 64 |
| NL56/117 | 56 | 142 | 60 | 117 | 43 | 102 | 42 |
| NL59/108 | 59 | 150 | 60 | 108 | 41 | 102 | 45 |
| NL64/95 | 64 | 163 | 60 | 95 | 37 | 102 | 49 |
| NL72/88 | 72 | 183 | 50 | 88 | 40 | 85 | 38 |
| NL76/79 | 76 | 193 | 52 | 79 | 36 | 88 | 43 |
| NL80/74 | 80 | 203 | 50 | 74 | 35 | 85 | 42 |
| NL88/71 | 88 | 224 | 42 | 71 | 39 | 71 | 33 |
| NL96/62 | 96 | 244 | 42 | 62 | 35 | 76 | 36 |
| NL100/55 | 100 | 254 | 42 | 55 | 31 | 80 | 37 |
| NL104/51 | 104 | 264 | 42 | 51 | 29 | 71 | 39 |
| NL110/46 | 110 | 279 | 42 | 46 | 25 | 76 | 41 |
| NL120/39 | 120 | 305 | 42 | 39 | 21 | 80 | 45 |
| NL120/43 | 120 | 305 | 38 | 43 | 25 | 65 | 37 |
| NL120/46 | 120 | 305 | 35 | 46 | 29 | 60 | 31 |
| NL130/32 | 130 | 330 | 43 | 32 | 17 | 73 | 51 |
| NL130/40 | 130 | 330 | 35 | 40 | 25 | 60 | 34 |
| NL140/35 | 140 | 356 | 35 | 35 | 22 | 60 | 36 |
| NL150/34 | 150 | 381 | 31 | 34 | 25 | 53 | 30 |
|
Remark:The above are theoretic data for reference only.Thickness error range±5% ; Mesh Opening & Open Area & Weight only slight error according to actual data. |
|||||||
Applications:
Nylon Filter Mesh is widely used in filteration, textile printing and dyeing, printing plate, electronic printing, ceramics, glass printing,the industries of petroleum, chemical, metallurgy, cement, environmental dedusting and mine. The fabric has been brushed, so it is more flexible and thicker,the dedusting efficiency can reach 99.99%.
