High hardness PU silk screen printing squeegee
| Place of Origin | Shanghai China |
|---|---|
| Brand Name | SPRING |
| Certification | ISO,CE,ROHS |
| Model Number | PU |
| Minimum Order Quantity | 1PC |
| Price | www.silk-screen-mesh.com |
| Packaging Details | 1. in roll with plastic 2.in wooden case or carton 3.as your requirement |
| Delivery Time | 3-7 Days |
| Payment Terms | TT/LC/Western Union/paypal/others |
| Supply Ability | 5000000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | PU | Feature | Anti-solvent Resistance, Abrasion Resistance |
|---|---|---|---|
| Edge Shape | Straight Square Edge,Double Bevel ,Single Bevel ,Round | Printing Type | Screen Printing Machine |
| Handle | Wooden Handle | Main Application | Bottle,canvas,CD / DVD,Printed Circuit Board |
| Packaging Details | 1. In Roll With Plastic 2.in Wooden Case Or Carton | Delivery Time | 3-7Days |
| Length /Roll | 4 Meter | Hardness | 55 Shore A~95 Shore A |
| Size | Standard And Customized | Free Sample | Accepted |
| Color | Any Color |
Product Description
High hardness PU silk screen printing squeegee
Squeegees are an essential tool for screen printing, probably the most important piece of equipment besides the actual screen! Shanghai SRING cooperated factory is established in 1988, with nearly 20 years experience, our factory imported the advance equipment, raw material from Europe and United states. With more than 300 skilled workers, the squeegees are well established in the world market.
Main Features:
1.Our squeegee made of special polyurethane elastomer have the following advantages.
2.High abrasion resistance and tear resistant better elasticty resulting in prints of uniformly high quality material.
3.Excellent resistance and minimum swell to a wide range of pastes,inlss and solvents.
4.Precisely finished edge.
5.Huper solvent resistance.
6.Long service life.
Specifications
1.Good rubber material
2.high solvent &wear resistant
3.regular spec:50*9mm,35*7mm, 5*25mm
4.easy scrape solvent,ink,etc.
Application:
is widely used in the following industry.
1.Graphic printing industry,
2.Solar industry
3.Textile screen printing industry
4.Ceramic industry
5.Electrionic circuit board industry
6.Bottle manufacturing industry
Hardness scope & Color
| Grade | Shore | Color | Common Color Sample |
| PU1 | 45-50 | Transparent | |
| PU2 | 50-55 | Light Yellow | |
| PU3 | 55-60 | Light Red | |
| PU4 | 60-65 | Red | |
| PU5 | 65-70 | Light Green | |
| PU6 | 70-75 | Green | |
| PU7 | 75-80 | Blue | |
| PU8 | 80-85 | Coffee | |
| PU9 | 85-90 | Light Brown | |
| PU10 | 90-95 | Pink |
Hardness Selections
| Red, Soft PU1-PU4 |
Suitable for low viscosity ink printing, low density or tough surface printing. |
| Green, Medium PU5-PU6 |
High pressure resistance. Suitable for high or low viscosity ink or high density surface printing. Could easily control the ink amount and assure the precision of the printing. |
| Blue, Hard PU7-PU10 |
Highest pressure and strongest ink solvent resistance. Could easily control the ink amount and get the highest quality printing. |
Size Selections
| Length | Width | Thickness |
| 2450mm100” | 9.5mm-320mm | 1mm-30mm |
| 3200mm126” | ||
| 3660mm144” | ||
| 4000mm157” |
Edge Selection:
Squeegee for Screen Printing Specification:
| Material | TDI, MDI, PPG, PTMG,PUetc. |
| Color | as requested |
| Hardness | 50-95(Shore A) |
| Density | 1.12-1.25g/cm3 |
| Tensile Strength | 25-55Mpa |
| Tear Strength | 85-155KN/M |
| Elongation | 450-650% |
| Impact Elasticity | >20-30% |
| Tolerance | 0.1-0.3mm |
| Working Temperature | 120°C(max) |
| Surface Finish | One side or both |
Packages:
1)Printing on the squeegees under request
2)Rolled in plastic bag
3)Small carton box for each roll
4)10 small cartons put into a big carton
5)Put into carton box
6)Special demand can be produced under request
Why us:
1.We believe in providing quality not just first time, but every time.
2.High customer’s satisfaction.
3.Focus on screen printing mesh and filtration cloth since 1983
4.Factory price, Best quality, excellent service( before or after sale)
5.One-stop service can be provided under request to save your time and cost.
6.At least 3-4times inspections before goods shipping out, the sales as the directly person with customers will check the goods not fixed time and goods.
7.Professional and highly motivated staffs.
