Screen printing mesh for carpet printing/screen printing mesh

Name: Screen printing mesh for carpet printing/screen printing mesh
Brand: SPRING
SKU: SP-SPM Silk Screen Mesh
Price: 0.4 USD
Availability: InStock
Rating: 4.6 (144 reviews)

Product Details:

Place of Origin:	CHINA
Brand Name:	SPRING
Certification:	ISO9001, FDA, ROSH, SGS
Model Number:	SP-SPM Silk Screen Mesh

Payment & Shipping Terms:

Minimum Order Quantity:	1 Square meter
Price:	US $0.4 - 1.4 / 1-50Meter
Packaging Details:	Waterproof plastic,Bubble bag,carton,Woven bag,Packing belt.
Delivery Time:	3-5 work days
Payment Terms:	L/C, , T/T, Western Union, MoneyGram
Supply Ability:	10000 Meter/Meters per WeeK Silk Screen Mesh

Contact Now

Detailed Product Description

Material:	100% Polyester Monofilament	Usage:	Silk Screen Mesh
Type:	100% Polyester Monofilament Silk Screen Mesh	Thickness:	100 μm 120μm 150μm Silk Screen Mesh
Length:	30-70m/roll Silk Screen Mesh	Width:	0.6m-3.65m Silk Screen Mesh
Hole Shape:	Square	Product Name:	Polyester Silk Screen Mesh For Procelain /Cloth/ PCB Printing
Other Name:	Polyester Silk Screen Mesh For Procelain /Cloth/ PCB Printing	Mesh Count:	15-420mesh/inch
Weave Style:	Plain Woven Silk Screen Mesh	Mesh Opening:	26um -1080um Silk Screen Mesh
Thread Dia:	31μm 350μm	Factory Advantage:	Lowest Price, Low MOQ
Free Samples:	Accepted	Our Advantages:	More Than 30 Years Professional Factory Experience

Screen printing mesh for carpet printing

Shanghai SPRING is a professional manufacturer and suppliers that is concerned with the design, development and production of Screen printing mesh for carpet printing.

Carpets on the printed word or pattern is usually 80 mesh to 150 mesh Rug printing cloth, with matching ink or water-based adhesive printing, specific to see the material, the use of matching printing ink or glue.

Screen printing mesh for carpet printing/screen printing mesh 0

Screen printing mesh for carpet printing/screen printing mesh 1

Application :

Mainly used for rug library printing and rug wireless printing, custom rug printing.

100% polyester monofilament screen printing mesh

Color: yellow, white
Width: 0.6m-3.7m

Length per roll: 30m, 50m or by customer's request

Specifications:

80 mesh,90 mesh,100 mesh,110 mesh,120 mesh,135 mesh,150 mesh etc.

Certification :

Fine mesh screen material have received FDA and SGS.

Screen printing mesh for carpet printing/screen printing mesh 2

Screen printing mesh for carpet printing/screen printing mesh 3

FAQ

1. What is the MOQ:

For the normal product, we don't have strictly limit about the Minimum Order Quantity. We can provide you small samples or the samples as you want to test our mesh sample, if ok, place trial order, then big orders.

2. How to pay the sample or trial cost or express cost:

Paypal, West union, Personal bank account, Company bank account as you hope.

3. How long time can be ship out for the sample and trial order:

Usually small order or samples takes 2-5days more or less.

4. Delivery time:

For normal items usually takes one week more or less under 5000M per order. For big orders we will confirm it for you when you place order. For special products also need to be confirmed before the order placed.

5. What kind of package of the goods?

Usually for normal orders, the mesh rolled on paper tube, then label card, then plastic bag, then carton box, then sailcloth outside.

6. When can you confirm the payment after we transfer?

We have special staff to check the money every day, we will inform you once we get it within 2hours.

7. DO you accept LC at sight?

Yes, we accept LC at sight for big orders. Usually, over 10,000$ LC at sight is acceptable.

Screen printing mesh for carpet printing
Mesh(T)/cm- wirediameter/μm	mesh/inch	Opening (μm)	Open area(%)	thickness(μm)	Theoretical ink volume(cm3/㎡)
13T-150	33	619	64	300	128
21T-150	55	326	46	260	118
24T-100	60	316	57	136	65
24T-120	60	296	51	162	83
28T-140	70	217	40	195	76
32T-55	81	257	67	103	67
32T-100	81	212	45	165	73
36T-90	92	183	44	150	65
39T-55	100	177	56	88	55
39T-80	100	176	48	125	60
43T-80	110	149	41	130	53
47T-55	120	152	61	88	48
48T-70	122	133	41	115	47
53T-55	135	133	50	86	42
54T-64	137	115	39	100	39
59T-55	150	114	45	95	43
61T-64	155	90	31	101	30
61T-70	155	94	33	120	40
64T-55	160	98	38	98	36
64T-64	160	85	30	115	34
68T-55	175	85	34	85	28
72T-48	182	90	36	78	33
72T-55	182	85	30	90	27
77T-48	195	77	35	80	28
77T-55	195	67	27	88	24
80T-48	200	72	33	74	25
90T-48	230	56	25	78	19
100T-40	255	58	33	63	21
120T-34	305	45	30	55	16
130T-34	330	40	27	55	15
140T-31	355	36	26	48	12
140T-34	355	31	20	53	10
150T-31	380	32	23	49	11
150T-34	380	23	13	55	6.5
165T-31	420	23	15	48	7

Production Process

We buy yarn from Jintong, Switzerland and Japan, we inspect the yarn when they unloaded in our factory. (tolerance, tensile strength, physics test etc.).

After that, we put the warp wire on beam, draw the warp wire into heddle and reed. Then our experienced weaver will start weaving according to orders.

Initial survey will be done after weaving.Then start heat setting treatment and physical properties inspection, before we get tentative finished rolls(60-500 meters big rolls).

In the end, we’ll cut the small rolls(20m-50m) according to customer orders after a final inspection.

Screen printing mesh for carpet printing/screen printing mesh 4
