Factory direct selling polyester printing mesh,nylon mesh,flour mesh.
Place of Origin: | CHINA |
Brand Name: | SPRING |
Certification: | ISO9001, FDA, ROSH, SGS |
Model Number: | SP-SPM Screen Printing Mesh |
Minimum Order Quantity: | 1 Square meter |
---|---|
Price: | US $0.4 - 1.4 / 1-50Meter |
Packaging Details: | Waterproof plastic,Bubble bag,carton,Woven bag,Packing belt. |
Delivery Time: | 3-5 work days |
Payment Terms: | L/C, , T/T, Western Union, MoneyGram |
Supply Ability: | 10000 Meter/Meters per WeeK Polyester Filter NET yarn Silk screen mesh |
Material: | 100% Polyester Monofilament | Usage: | Screen Printing Mesh |
---|---|---|---|
Type: | 100% Polyester Monofilament Screen Printing Mesh | Thickness: | 100 μm 120μm 150μm Screen Printing Mesh |
Length: | 30-70m/roll Screen Printing Mesh | Width: | 0.6m-3.65m Screen Printing Mesh |
Hole Shape: | Square | Product Name: | 20T 21T 50 MESH WIRE DIA 100 μm 120μm 150μm Polyester Filter NET Yarn Silk Screen Mesh |
Other Name: | 20T 21T 50 MESH WIRE DIA 100 μm 120μm 150μm Polyester Filter NET Yarn Silk Screen Mesh | Mesh Count: | 20T 21T 50 MESH |
Weave Style: | Plain Woven Screen Printing Mesh | Mesh Opening: | 350 380 400um Screen Printing Mesh |
Thread Dia: | 100 μm 120μm 150μm | Factory Advantage: | Lowest Price, Low MOQ |
Free Samples: | Accepted | Our Advantages: | More Than 30 Years Professional Factory Experience |
20T 21T 50 MESH WIRE DIA 100 μm 120μm 150μm Polyester Filter NET yarn Silk screen mesh
Product Description
Most competitive price, high quality, low elongation and high tension strength
Color: yellow, white
Width: 0.6m-3.6m
Length per roll: 30m, 50m, 30yard, 60yard or by customer's request
polyester screen mesh for printing
100% polyester monofilament screen printing mesh
Polyester screen printing mesh
Silk screen printing mesh
Polyester polyester screen printing gauze | |||||
Mesh(T)/cm- wirediameter/μm |
mesh/inch | Opening (μm) | Open area(%) | thickness(μm) | Theoretical ink volume(cm3/㎡) |
13T-150 | 33 | 619 | 64 | 300 | 128 |
21T-150 | 55 | 326 | 46 | 260 | 118 |
24T-100 | 60 | 316 | 57 | 136 | 65 |
24T-120 | 60 | 296 | 51 | 162 | 83 |
28T-140 | 70 | 217 | 40 | 195 | 76 |
32T-55 | 81 | 257 | 67 | 103 | 67 |
32T-100 | 81 | 212 | 45 | 165 | 73 |
36T-90 | 92 | 183 | 44 | 150 | 65 |
39T-55 | 100 | 177 | 56 | 88 | 55 |
39T-80 | 100 | 176 | 48 | 125 | 60 |
43T-80 | 110 | 149 | 41 | 130 | 53 |
47T-55 | 120 | 152 | 61 | 88 | 48 |
48T-70 | 122 | 133 | 41 | 115 | 47 |
53T-55 | 135 | 133 | 50 | 86 | 42 |
54T-64 | 137 | 115 | 39 | 100 | 39 |
59T-55 | 150 | 114 | 45 | 95 | 43 |
61T-64 | 155 | 90 | 31 | 101 | 30 |
61T-70 | 155 | 94 | 33 | 120 | 40 |
64T-55 | 160 | 98 | 38 | 98 | 36 |
64T-64 | 160 | 85 | 30 | 115 | 34 |
68T-55 | 175 | 85 | 34 | 85 | 28 |
72T-48 | 182 | 90 | 36 | 78 | 33 |
72T-55 | 182 | 85 | 30 | 90 | 27 |
77T-48 | 195 | 77 | 35 | 80 | 28 |
77T-55 | 195 | 67 | 27 | 88 | 24 |
80T-48 | 200 | 72 | 33 | 74 | 25 |
90T-48 | 230 | 56 | 25 | 78 | 19 |
100T-40 | 255 | 58 | 33 | 63 | 21 |
120T-34 | 305 | 45 | 30 | 55 | 16 |
130T-34 | 330 | 40 | 27 | 55 | 15 |
140T-31 | 355 | 36 | 26 | 48 | 12 |
140T-34 | 355 | 31 | 20 | 53 | 10 |
150T-31 | 380 | 32 | 23 | 49 | 11 |
150T-34 | 380 | 23 | 13 | 55 | 6.5 |
165T-31 | 420 | 23 | 15 | 48 | 7 |
Spring ensure the quality.
We buy yarn from Jintong, Switzerland and Japan, we inspect the yarn when they unloaded in our factory. (tolerance, tensile strength, physics test etc.).
After that, we put the warp wire on beam, draw the warp wire into heddle and reed. Then our experienced weaver will start weaving according to orders.
Initial survey will be done after weaving.Then start heat setting treatment and physical properties inspection, before we get tentative finished rolls(60-500 meters big rolls).
In the end, we’ll cut the small rolls(20m-50m) according to customer orders after a final inspection.
Application Filed:
1.T-shirt /garment Commercial T-shirts/garment, advertising, fashion and sports clothing,
Flatbed textile Knitted fabric, blanket, chiffon silk even denim
High-end textile Full saturate front and back of the fabrics
Recommend mesh 10T-120T polyester screen printing mesh
2. Pharmacy appliance, Home appliance, Automotive glass, Glass container, etc.
Recommend mesh 39T-165Tpolyester screen printing mesh
3. Domestic ceramic, Indirect Ceramic, Ceramic tiles, etc.
Recommend mesh 39T-165T polyester screen printing mesh
4. Stickers, labels, Small/Large Format UV Graphics, Package graphics, plastics, etc.
Recommend mesh 10T-165T polyester screen printing mesh
5. Plastic package, plastic package, plastic bottle, advertising, plastic decoration, etc.
Recommend mesh 36T-165T polyester screen printing mesh
6. CD/DVD, PCB membrane switches/touch screen, PV and other high-grade electronic products
Recommend mesh 72T-165T polyester screen printing mesh
Our polyester screen printing mesh used for textile printing or glass printing or carpet printing, pcb printing, touch screen printing, etc. It is also widely used for filteration. Such as water filteration, chemical filter, milk filter, powder filter, etc.
Our Factory
Shanghai SPRING Industrial Corporation as a professional manufacture of monofilament screen mesh, we have more than 30 years experience in this line since 1983. We have full size mesh from 18mesh to 500mesh with different width and colors can be provided. We have more than 150sets Sulzer Ruti P7100 and P7300 weaving machines to make sure the goods can be produced with good surface and high tension we use the best quality yarn from China also imported from Japan for high count mesh. The max width 390CM to make sure the width can satisfy the customers demand.
Packaging and shipping:
The common packaging:
1.30-70m/roll in PVC bag
2.2-8 rolls per carton
3.waterproof bags outside
4.package belt strengthen
The common shipping:
