304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth

  • 304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth
  • 304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth
  • 304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth
  • 304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth
  • 304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth
Place of Origin CHINA
Brand Name SPRING
Certification iso9001
Minimum Order Quantity 30m
Price www.silkscreenmesh.com
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 2-5 Days
Payment Terms TT/LC/Western Union/paypal/others
Supply Ability 5500000m/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 316L Specification Customization
Aperture 0.033 (mm) Wire Diameter 0.018 (mm)
Weaving Method Plain Weave Filtration Accuracy 500
Maximum Differential Pressure 700 Operating Temperature 100
Use Filter
Leave a Message
Product Description
product description:

Stainless steel mesh is classified by type:
1. Stainless steel plain weave.
2, stainless steel twill net.
3, stainless steel bamboo pattern net.
4, five comprehensive stainless steel mesh.
5, stainless steel punching net.
6, stainless steel ginning net.
7, stainless steel chain link flower net.
8, stainless steel mesh.
9, stainless steel welded wire mesh.
10, stainless steel hexagonal net.
11, stainless steel mat network.
12, stainless steel barbecue net.
13, stainless steel ore screen.
14, stainless steel tortoise shell net.
Material: SUS302, 304, 304L, 316, 316L, 310s
Material: stainless steel wire, stainless steel plate type stainless steel heat resistant, acid resistant, corrosion resistant, wear resistant.

Stainless steel mesh, also known as stainless steel mesh, stainless steel mesh, stainless steel filter, stainless steel wire mesh, etc.

Production process: radial and weft wire diameters are the same, each wire crosses every two (or more) wefts, and each weft crosses every two (or more) wires Made up and down with a fork.

Weaving method: plain, twill, mat weave.

Material: 201, 304, 304L, 321, 316, 316L, 310S, 2250, 2520, 914 and other materials.

Width: Common width 1 m 1.2 m 1.5 m, more than 2 meters to 6 meters can be processed and ordered.

Length: 30 meters, according to customer requirements.

Shape: roll shape, and can be punched into square pieces, wafers and other shapes, can also be processed into other filter equipment.

Packing: Generally wrapped in kraft paper, outsourced waterproof paper.

Performance: acid resistance, alkali resistance, high temperature resistance, tensile strength, wear resistance, etc.

Uses: Used for screening and filtration under acid and alkali environmental conditions, as a mud net in the petroleum industry, as a sieve filter in the chemical fiber industry, and as a pickling net in the electroplating industry. It can also be used in petroleum, chemical, construction, textile, pharmaceutical, aviation, aerospace, railway, highway, garden protection, aquatic products, aquaculture, metallurgy, national defense, coal, minerals, light industry, decoration, agriculture, forestry, parks, machinery and other fields. Sound insulation wall, roof, powder layer, large mine screen, electronics industry and household appliances, mechanical equipment safety protection and motor blade housing, air filter and heat treatment.
304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 0
304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 1304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 2304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 3304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 4304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 5304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 6304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 7
304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 8304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 9304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 10304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 11304 stainless steel mesh 100 mesh stainless steel filter oil and gas separation high mesh stainless steel filter cloth 12
Stainless steel mesh number wire diameter weight comparison table
Weaving method Weaving method Wire diameter (mm) Mesh (mm) Weight (kg / square meter)
Plain weave 1mesh 2mm 23.4 2
Plain weave 2mesh 1.5mm 11.2 2.25
Plain weave 3mesh 1.0mm 7.466 1.5
Plain weave 4mesh 0.9mm 5.45 1.62
Plain weave 5mesh 0.8mm 4.28 1.6
Plain weave 6mesh 0.7mm 3.53 1.47
Plain weave 7mesh 0.6mm 3.02 1.26
Plain weave 8mesh 0.5mm 2.675 1
Plain weave 9mesh 0.5mm 2.322 1.125
Plain weave 10mesh 0.8mm 1.74 3.2
Plain weave 11mesh 0.7mm 1.609 2.695
Plain weave 12mesh 0.6mm 1.516 2.16
Plain weave 13mesh 0.5mm 1.453 1.625
Plain weave 14mesh 0.4mm 1.414 1.12
Plain weave 15mesh 0.4mm 1.293 1.2
Plain weave 16mesh 0.35mm 1.237 0.98
Plain weave 17mesh 0.35mm 1.144 1.041
Plain weave 18mesh 0.35mm 1.061 1.1
Plain weave 19mesh 0.35mm 0.986 1.16
Plain weave 20mesh 0.4mm 0.97 0.97
Plain weave 21mesh 0.3mm 0.909 0.945
Plain weave 22mesh 0.3mm 0.854 0.99
Plain weave 23mesh 0.25mm 0.854 0.718
Plain weave 24mesh 0.25mm 0.858 0.48
Plain weave 25mesh 0.2mm 0.816 0.5
Plain weave 26mesh 0.2mm 0.776 0.52
Plain weave 27mesh 0.2mm 0.74 0.54
Plain weave 28mesh 0.3mm 0.607 1.26
Plain weave 29mesh 0.3mm 0.575 1.3
Plain weave 30mesh 0.3mm 0.546 1.35
Plain weave 40mesh 0.25mm 0.385 1.25
Plain weave 50mesh 0.2mm 0.308 1
Plain weave 60mesh 0.15mm 0.273 0.675
Plain weave 70mesh 0.14mm 0.222 0.686
Plain weave 80mesh 0.12mm 0.197 0.576
Plain weave 90mesh 0.11mm 0.172 0.544
Plain weave 100mesh 0.10mm 0.154 0.5
Plain weave 120mesh 0.08mm 0.131 0.384
Plain weave 150mesh 0.07mm 0.099 0.367
Plain weave 380mesh 0.02mm 0.046 0.076
Plain weave 400mesh 0.018mm 0.0455 0.0648
