Factory offer 7T-180T polyester monofilament mesh bolting cloth White or yellow or black color available
| Place of Origin | SHANGHAI |
|---|---|
| Brand Name | SPRING |
| Certification | ISO9001 |
| Model Number | DPP |
| Minimum Order Quantity | 30M |
| Price | www.silk-screen-mesh.com |
| Packaging Details | Paper tube, plastic bag, carton box, sailcloth |
| Delivery Time | 2-5 Days according to the quantity |
| Payment Terms | TT/LC/Western Union/paypal/others |
| Supply Ability | 5500000m/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 100% Polyester Print Mimeograph Material Mesh Screen | Material | 100% Polyester |
|---|---|---|---|
| Weave Type | Plain | Elastcity | Low |
| Width | 1.0m-3.7m | Color | White Yellow Black |
| Length | 50m In Standard Or Make To Order | Weaving Machine | Sulzer Ruti |
Product Description
Factory offer 7T-180T polyester monofilament mesh bolting cloth White or yellow or black color available
Factory Introduce:
Shanghai SPRING produce the mesh since 1983, factory name change into company name in 1986, then export department changed the name on 2012. We have most professional engineers with more than 30years experience to make sure the goods quality. We import the sulzer Ruti machine and Benninger warping machine with 8sets heat settiing machine include the imported Germany made reed, make sure the mesh with high tension and low elongation. We can produce even 5mircon mesh under the request. If you have any special request about the mesh, just don't hesitate to contact us. You will benefit from us more than what you expected. Double win is what we hope, hope our customers and our company can grow up together.
Screen printing mesh specification: 18 mesh-460 mesh
Common widths 115 127 136 146 158 165 220 310 340 370
The colors are white black yellow orange.
Screen printing screen yarn features: smooth surface, 18-420 mesh, heat resistance, high temperature resistance, corrosion resistance, stable tension, low elongation, good screen printing performance, and many printing times.
Screen printing net yarn use: Mainly used in glass, printing, tile printing, electronics industry, advertising, arts and crafts, mobile phone speakers, speakers, silk chemical fiber, ceramic printing, printed circuit boards, printing plates, sign advertising, flower paper, filtration, Luggage, environmental protection and other industries
Application:
T-shirt: General water-based inks are suitable for absorbent substrates with rough screen surface. To achieve the best coverage of the ink layer, a larger amount of ink is required, so a thicker screen is used. (120-180 mesh)
Brand-name advertising: solvent-based inks are printed with medium mesh gauze when printing advertisements and electrical appliances. (195-420 mesh)
Circuit board: The pigment particles of general inks for electronic products are relatively fine, and the ink has good versatility. This kind of use has a high mesh number. (90-355 mesh)
Ceramic cups: ceramics generally have a high mesh count. Such smooth non-absorbent substrates require less ink, so a high mesh screen (80-355 mesh) is selected.
| 100% Polyester Monofilament Mesh | |||||||
| Type | Weave | Mesh/CM | Mesh/inch | Wire Dia. (um) |
Mesh Opening(um) | Open Area (%) |
Thickness (um) |
| PET-7/1080 | PW | 7 | 18 | 350 | 1080 | 57 | 640 |
| PET-8/950 | PW | 8 | 20 | 300 | 950 | 58 | 550 |
| PET-10/800 | PW | 10 | 25 | 200 | 800 | 64 | 380 |
| PET-10/750 | PW | 10 | 25 | 250 | 750 | 56 | 480 |
| PET-12/633 | PW | 12 | 30 | 200 | 633 | 58 | 390 |
| PET-12/583 | PW | 12 | 30 | 250 | 583 | 49 | 480 |
| PET-16/425 | PW | 16 | 40 | 200 | 425 | 46 | 400 |
| PET-20/420 | PW | 20 | 50 | 80 | 420 | 71 | 140 |
| PET-20/400 | PW | 20 | 50 | 100 | 400 | 64 | 185 |
| PET-20/380 | PW | 20 | 50 | 120 | 380 | 58 | 230 |
| PET-20/350 | PW | 20 | 50 | 150 | 350 | 49 | 290 |
| PET-24/337 | PW | 24 | 60 | 80 | 337 | 65 | 150 |
| PET-24/317 | PW | 24 | 60 | 100 | 317 | 58 | 190 |
| PET-24/297 | PW | 24 | 60 | 120 | 297 | 51 | 235 |
| PET-24/267 | PW | 24 | 60 | 150 | 267 | 41 | 295 |
| PET-29/225 | PW | 29 | 74 | 120 | 225 | 43 | 238 |
| PET-32/249 | PW | 32 | 80 | 64 | 249 | 63 | 115 |
| PET-32/233 | PW | 32 | 80 | 80 | 233 | 55 | 150 |
| PET-32/213 | PW | 32 | 80 | 100 | 213 | 46 | 180 |
| PET-34/194 | PW | 34 | 86 | 100 | 194 | 44 | 185 |
| PET-36/178 | PW | 36 | 90 | 100 | 178 | 41 | 190 |
| PET-39/201 | PW | 39 | 99 | 55 | 201 | 62 | 90 |
| PET-39/176 | PW | 39 | 99 | 80 | 176 | 47 | 150 |
| PET-39/156 | PW | 39 | 99 | 100 | 156 | 37 | 195 |
| PET-43/153 | PW | 43 | 110 | 80 | 153 | 43 | 155 |
| PET-47/158 | PW | 47 | 120 | 55 | 158 | 55 | 95 |
| PET-47/142 | PW | 47 | 120 | 71 | 142 | 44 | 130 |
| PET-53/134 | PW | 53 | 135 | 55 | 134 | 50 | 98 |
| PET-53/125 | PW | 53 | 135 | 64 | 125 | 44 | 115 |
| PET-53/118 | PW | 53 | 135 | 71 | 118 | 39 | 133 |
| PET-59/114 | PW | 59 | 150 | 55 | 114 | 46 | 100 |
| PET-59/105 | PW | 59 | 150 | 64 | 105 | 39 | 118 |
| PET-64/101 | PW | 64 | 163 | 55 | 101 | 42 | 102 |
| PET-64/92 | PW | 64 | 163 | 64 | 92 | 35 | 120 |
| PET-72/91 | PW | 72 | 183 | 48 | 91 | 43 | 75 |
| PET-72/84 | PW | 72 | 183 | 55 | 84 | 37 | 105 |
| PET-77/75 | PW | 77 | 195 | 55 | 75 | 33 | 108 |
| PET-80/77 | PW | 80 | 203 | 48 | 77 | 38 | 77 |
| PET-90/63 | PW | 90 | 230 | 48 | 63 | 32 | 80 |
| PET-100/60 | PW | 100 | 254 | 40 | 60 | 36 | 65 |
| PET-110/51 | PW | 110 | 280 | 40 | 51 | 31 | 70 |
| PET-120/48 | PW | 120 | 305 | 34 | 48 | 35 | 63 |
| PET-120/43 | PW | 120 | 305 | 40 | 43 | 27 | 75 |
| PET-140/37 | PW | 140 | 355 | 34 | 37 | 27 | 65 |
| PET-140/36 | PW | 150 | 380 | 31 | 36 | 29 | 52 |
| PET-150/33 | PW | 150 | 380 | 34 | 33 | 24 | 56 |
| PET-165/34 | PW | 165 | 420 | 27 | 34 | 31 | 50 |
| PET-165/30 | PW | 165 | 420 | 31 | 30 | 24 | 58 |
