Polyester Spiral Belt

Polyester Spiral Belt

  • Polyester Spiral Belt
Polyester Spiral Belt
Product Details:
Place of Origin: China
Brand Name: SPRING
Certification: ISO9001;ISO14001
Model Number: DPP
Payment & Shipping Terms:
Minimum Order Quantity: 30m
Price: www.springscreenmesh.com
Packaging Details: Paper tube, plastic bag, carton box, sailcloth
Delivery Time: 2-5 Days
Payment Terms: TT/LC/Western Union/paypal/others
Supply Ability: 5000000m/month
Contact Now
Detailed Product Description
Mesh Count: 7T-180T Material: 100% Polyester
Weave Type: Plain Elasticity: Low
Printing: Polyester Screen Printing Monofilament Style: Yes
Highlight:

Polyester Spiral Belt

,

Spiral Belt

,

bolting cloth

Introduction:
Polyester Spiral Filter Screen:Polyester monofilament,made of polyester spiral dryer fabric which is filled with stuff to reduce the air permeation and to intensitive the opening, hence to reduce the material loss from the mesh opening.

Applications:
Mainly used in sludge desiccation, paper pulp washing, coal washing, chemicals, dehydration of wine bran, vinegar bran dehydration and other industries. It is better in the high ventilation part of the dryness part of paper-making machine.

Specifications & Details:

Model

Thread Diameter
(mm)

Thickness(mm)

Weight(kg/m2)

Air Permeability
(m3/m2h)

Warp

Weft







4070B

0.9

1.1

3

1.7

20500+-1500

4070A

0.9

1.1

3

1.9

5250+-500

3868B

0.7

0.9

2.5

1.4

18500+-1500

3868A

0.7

0.9

2.5

1.7

4750+-500

3252B

0.5

0.7

1.9

1.1

15000+-1500

3252A

0.5

0.7

1.9

1.4

4000+-500
