Dust Filter Bags/Nylon Net
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Mesh Count | 4T-130T | Material | Nylon |
|---|---|---|---|
| Weave Type | Plain | Elasticity | Low |
| Printing | Bags | Monofilament Style | Yes |
Product Description
Dust Filter Bags/Nylon Net
Dust Filter Bags/Nylon Net Features & advantages:
*Needle felts with high particle retention and air permeability
*For low pressure filters we generally use PET 350g/m2 material
*For high pressure and pocket filters we use PET 500 g/m2
*High strength quality of needle felts
*Felts can be treated to be:
oleophobic
hydrophobic
antistatic
*Standard welded longitudinal seam
*Standard bags are available from stock. Special dimensions or designs are made to order.
*For low pressure filters we generally use PET 350g/m2 material
*For high pressure and pocket filters we use PET 500 g/m2
*High strength quality of needle felts
*Felts can be treated to be:
oleophobic
hydrophobic
antistatic
*Standard welded longitudinal seam
*Standard bags are available from stock. Special dimensions or designs are made to order.
Dust Filter Bags/Nylon Net Specifications:
*Material: 100% nylon (polyester available if needed)
*Weaving: Plain weave (Twill weave available if needed)
*Mesh Count: 4T~140T mesh/cm(11mesh~355 mesh/inch)
*Max. Width: 365cm (143 inch)
*Color: White/yellow/black
Dust Filter Bags/Nylon Net Specifications:
|
Sizes:
|
IN
|
CM
|
|
Size 1
|
7" x 16"
|
17.8 x 40.65
|
|
Size 2
|
7" x 32"
|
17.8 x 81.3
|
|
Size 3*
|
4" x 8.25"
|
10.2 x 20.9
|
|
Size 4*
|
4" x 14"
|
10.2 x 35.5
|
|
* Sizes 3 and 4 in NMO material are available with welded seams
|
||
|
Size 3 WE
|
4" x 6"
|
10.2 x 15.24
|
|
Size 4 WE
|
4" x 12"
|
10.2 x 30.48
|
|
Maximum Operating Temperatures
|
||
|
Nylon
|
275-300 F
|
135-149 C
|
|
Polypropylene
|
200-220 F
|
93-104C
|
|
Polyester
|
275-325 F
|
132-162 C
|
|
Material
|
Nylon
Monofilament |
Polyester
Multifilament |
Polypropylene
Monofilament |
Polyester
Monofilament* |
|
Nomenclature
|
NMO
|
PEM
|
PMO
|
PEMO
|
|
Microns
|
1
|
75
|
100
|
75
|
|
|
5
|
100
|
150
|
100
|
|
|
10
|
125
|
200
|
400
|
|
|
25
|
150
|
250
|
|
|
|
35
|
200
|
300
|
|
|
|
55
|
250
|
600
|
|
|
|
65
|
300
|
800
|
|
|
|
75
|
400
|
|
|
|
|
100
|
600
|
|
|
|
|
125
|
800
|
|
|
|
|
150
|
1500
|
|
|
|
|
175
|
|
|
|
|
|
200
|
|
|
|
|
|
250
|
|
|
|
|
|
300
|
|
|
|
|
|
400
|
|
|
|
|
|
600
|
|
|
|
|
|
800
|
|
|
|
|
|
1200
|
|
|
|
|
*Requires special order
|
||||
