Screen Printing Mesh for Automotive Glass/china factory

Screen Printing Mesh for Automotive Glass/china factory

  • Screen Printing Mesh for Automotive Glass/china factory
Screen Printing Mesh for Automotive Glass/china factory
Product Details:
Place of Origin: Shanghai China
Brand Name: SPRING
Certification: ISO9001
Model Number: JPP
Payment & Shipping Terms:
Minimum Order Quantity: 30m
Price: US $ 0.25 - 1.5 / m
Packaging Details: Paper tube, plastic bag, carton box, sailcloth
Delivery Time: 2-5 Days
Payment Terms: TT/LC/Western Union/paypal/others
Supply Ability: 5500000m/month
Contact Now
Detailed Product Description
Mesh Count: 4-140T Material: Nylon
Weave Type: Plain Elasticity: Low
Printing: Silk Screen Printing Monofilament Style: Yes

Nylon Mesh(For Printing and Filtration)

1.General introduction:

Nylon mesh for screen printing mesh.

1)Material: 100% nylon (polyester available if needed)

2)Weaving: Plain weave (Twill weave available if needed)

3)Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)

4)Max. width: 365cm (143 inch)

5)Color: white/yellow/black

We can provide products in special specifications according to your demand.



Nylon mesh for filtration:

1)Material: 100% nylon (polyester available if needed)

2)Weaving: Plain weave (Twill weave available if needed)

3)Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)

4)Max. width: 365cm (143 inch)

5)Color: white/yellow/black

We can provide products in special specifications according to your demand.



2.Technical specifications of our nylon mesh

Model

specification       (/cm)

Mesh count (mesh/inch)

Thread Diameter     (um)

Mesh opening(um)

Open Area(%)

Thickness(um)

Theoretic ink volme(cm3/m2)

NL5/1500

5

13

500

1500

56

1000

308

NL6/1267

6

15

400

1267

58

840

228

NL7/1079

7

18

350

1079

57

640

209

NL8/900

8

20

350

900

52

645

232

NL9/861

9

24

250

861

60

460

145

NL10/750

10

25

250

750

56

530

148

NL12/533

12

30

300

533

41

495

256

NL14/514

14

35

200

514

52

380

135

NL16/425

16

40

200

425

46

400

155

NL16/375

16

40

250

375

36

420

240

NL17/388

17

42

200

388

44

380

160

NL18/366

18

45

220

366

37

400

207

NL20/300

20

50

200

300

36

375

190

NL24/267

24

60

150

267

41

305

130

NL28/207

28

70

150

207

34

278

150

NL30/213

30

76

120

213

41

230

105

NL32/213

32

80

100

213

46

240

77

NL36/178

36

90

100

178

41

195

86

NL40/150

40

100

100

150

36

192

95

NL44/127

44

110

100

127

31

175

105

NL48/128

48

120

80

128

38

150

73

NL56/120

56

142

60

120

44

110

48

NL59/110

59

150

60

110

42

98

50

NL64/96

64

163

60

96

38

120

55

NL72/89

72

183

50

89

41

90

44

NL80/75

80

203

50

75

36

93

48

NL88/74

88

224

43

74

42

65

34

NL96/64

96

244

43

64

38

76

37

NL100/60

100

254

43

60

36

78

39

NL104/56

104

264

43

56

34

79

35

NL110/48

110

280

43

48

28

79

38

NL120/43

120

305

43

43

27

80

46

NL130/34

130

330

43

34

20

85

29

NL140/33

140

355

38

33

21

85

28

Remark: The following datas are theoretic ,please reference the actual data if there is a difference!
