Flour Filter Mesh
| Place of Origin | China |
|---|---|
| Brand Name | SPRING |
| Certification | ISO9001;ISO14001 |
| Model Number | GG & XXX |
| Minimum Order Quantity | 30m |
| Price | www.springscreenmesh.com |
| Packaging Details | Paper tube, plastic bag, carton box, sailcloth |
| Delivery Time | 2-5Days |
| Payment Terms | TT/LC/Western Union/paypal/others |
| Supply Ability | 500000m/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Mesh Count | 7T~180T Mesh | Material | 100% Polyester |
|---|---|---|---|
| Weave Type | Plain | Printing | Polyester Screen Printing |
| Elasticity | Low | Monofilament Style | Yes |
Product Description
Flour mesh as one of our mainly products, it is widely used for flour milling machine make a process of grinding and separating, done by roller-mills, sifters and purifiers. Such as flour, com, grain sifter, etc
Small order quantity can be accept and it have two series, XXX series and GG series.
Production Process :
_raw yarn inspection process
_warping
_drawstring
_weaving
_initial survey
_washing
_heat setting treatment
_physical properties inspection
_product inspection
_raw yarn inspection process
_warping
_drawstring
_weaving
_initial survey
_washing
_heat setting treatment
_physical properties inspection
_product inspection
Features & Specifications :
1.Material:100% polyester (Nylon available upon request)
2.Weaving: Plain weave (Twill weave available upon request)
3.Specs:7T~180T mesh/cm (20mesh/inch~420mesh/inch)
4.Max. Width:365cm (143")
5.Color: white and yellow (available upon request)
Can be customized upon appropriate specifications
Payment: T/T and Irrevocable L/C at sight
Samples available under freight burden by buyer, the cost refund after order is fixed
Normal sample time: 2 days
1.Material:100% polyester (Nylon available upon request)
2.Weaving: Plain weave (Twill weave available upon request)
3.Specs:7T~180T mesh/cm (20mesh/inch~420mesh/inch)
4.Max. Width:365cm (143")
5.Color: white and yellow (available upon request)
Can be customized upon appropriate specifications
Payment: T/T and Irrevocable L/C at sight
Samples available under freight burden by buyer, the cost refund after order is fixed
Normal sample time: 2 days
Exact Specifications & Details :
|
Type
|
Thread /cm
|
thread/inch
|
Open surface (%)
|
Opening(micron)
|
Weight/m2
|
|
6xxx
|
30/34
|
76/86
|
49
|
210
|
55
|
|
7xxx
|
33/36
|
84/91
|
47
|
200
|
57
|
|
8xxx
|
36/40
|
91/102
|
45
|
175
|
53
|
|
9xxx
|
43/48
|
109/122
|
45
|
150
|
49
|
|
10xxx
|
49/52
|
124/132
|
43
|
132
|
47
|
|
11xxx
|
53/60
|
135/152
|
44
|
117
|
40
|
|
12xxx
|
55/63
|
140/160
|
42
|
110
|
42
|
|
13xxx
|
58/68
|
147/173
|
39
|
100
|
45
|
|
14xxx
|
62/69
|
157/175
|
40
|
97
|
40
|
|
15xxx
|
65/74
|
165/188
|
38
|
90
|
42
|
|
12GG
|
4.5
|
11
|
67
|
1822
|
153
|
|
14GG
|
5
|
13
|
64
|
1600
|
170
|
|
15GG
|
5.5
|
14
|
61
|
1418
|
187
|
|
16GG
|
6
|
15
|
62
|
1317
|
156
|
|
18GG
|
6.5
|
17
|
59
|
1180
|
170
|
|
19GG
|
7
|
18
|
57
|
1079
|
182
|
|
20GG
|
7.5
|
19
|
60
|
1023
|
144
|
|
22GG
|
8
|
20
|
58
|
950
|
153
|
|
24GG
|
8.5
|
22
|
56
|
876
|
163
|
|
26GG
|
9
|
23
|
54
|
811
|
172
|
|
27GG
|
10
|
25
|
56
|
750
|
133
|
|
28GG
|
10.5
|
27
|
54
|
700
|
140
|
|
30GG
|
11
|
28
|
53
|
659
|
146
|
|
31GG
|
11.5
|
29
|
51
|
619
|
153
|
|
34GG
|
12
|
30
|
49
|
583
|
159
|
|
36GG
|
12.5
|
32
|
47
|
550
|
166
|
|
38GG
|
14
|
36
|
52
|
514
|
119
|
|
40GG
|
14.5
|
37
|
50
|
489
|
123
|
|
42GG
|
15
|
38
|
49
|
466
|
128
|
|
44GG
|
16
|
41
|
46
|
425
|
136
|
|
46GG
|
17
|
43
|
44
|
388
|
145
|
|
50GG
|
18
|
46
|
41
|
355
|
153
|
|
52GG
|
20.5
|
52
|
48
|
338
|
98
|
|
54GG
|
21.5
|
55
|
46
|
315
|
103
|
|
58GG
|
22
|
56
|
45
|
304
|
105
|
|
60GG
|
23
|
58
|
43
|
285
|
110
|
|
62GG
|
23.5
|
60
|
42
|
275
|
112
|
|
64GG
|
24
|
61
|
41
|
267
|
115
|
|
66GG
|
28.5
|
72
|
51
|
251
|
61
|
|
68GG
|
29
|
74
|
50
|
245
|
63
|
|
70GG
|
29.5
|
75
|
48
|
239
|
64
|
|
72GG
|
30.5
|
77
|
47
|
227
|
66
|
|
74GG
|
32
|
81
|
46
|
210
|
69
|
