square perforated screen

Place of Origin China
Brand Name SPRING
Certification ISO9001
Model Number sx-all
Minimum Order Quantity 30m
Price www.springscreenmesh.com
Packaging Details Paper tube, plastic bag, carton box, sailcloth
Delivery Time 2-5 Days
Payment Terms TT/LC/Western Union/paypal/others
Supply Ability 500000m/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Low-Carbon Iron Wire Weave Type Perforated Mesh
Leave a Message
Product Description

Specifications

Perforated Metal Screen/sheet

(1)low carbon steel plate, stainless steel plate
(2)strong and durable.
(3)winding-resisting

Perforated Metal Screen/sheet

Shanghai Spring Industrial Corporation can supply perforated metals in sheets or coils, in stainless steel, brass, iron and other metals. Perforated metal products can be made into screens, filters, baskets, trash cans, tubing, light fixtures, vents, audio speaker covers and patio furniture. Like expanded metals, perforated metals are also used for filtration, reinforcement and decoration in the form of sheets, gratings, flooring, angle beads, etc.


General Metal Sheets Sizes for Perforating:
Standard perforated metal sheets we supply are size 1000 x2000 mm, thicknesses from 0,3 mm up to 10 mm and perforation from 0,3 mm up to 100 mm. Our maximum material thickness, which we can perforate up to, is 25mm, the most common thickness range for balustrade infill, cladding panels etc. is between 1.5mm and 3.0mm although heavier specifications do away with having to frame the sheets with something like edging profile which we also supply.

The maximum width we can perforate up to is 2mt, the preferred maximum is 1.5mt.
The maximum length we can perforate up to is 6mt, the preferred maximum is 4mt.

General Perforation Openings:
Perforation range: round, square and rectangular holes.
We perforate a wide range of round, square, slotted, decorative and even odd shaped perforations on special request. Percentage open area, the most common percentage open area is between 30% and 50% although more extreme open areas are available depending on the perforation. Some times the percentage open area has to be kept lower for increased strength and flatness of the sheet especially when galvanising.

Perforated Metal Sheet Materials:
The most common material types are mild steel, Pre-galvanised mild steel, stainless steel, aluminium, brass and some types of plastics.

Perforated metal is used in many applications such balustrade infill, acoustics, security screens, air-condition units, radiator covers, screening, reinforcement and decoration in the form of sheets, gratings, flooring, angle beads, etc.
