high tension polyester silk screen mesh fabric for printing/screen printing mesh
Place of Origin | Shanghai China |
---|---|
Brand Name | SPRING |
Certification | ISO9001,ISO14001,FDA,SGS |
Model Number | DPP |
Minimum Order Quantity | 30m |
Price | 0.75-5.68$/m |
Packaging Details | Waterproof plastic,Bubble bag,carton,Woven bag,Packing belt. |
Delivery Time | 3-5 work days |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 10000m/day |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMateril | Polyester | Colour | Yellow / White / Black / Orange |
---|---|---|---|
Width | 0.1m-3.7m | Weave Type | Plain |
Elasticity | Low | Mesh Count | 18mesh-500mesh |
Roll Length | 30-70 M/roll | Free Sample | Accepted |
HS Code | 5911200090 |
high tension polyester silk screen mesh fabric for printing/screen printing mesh
Silk Screen Printing Mesh Application.pdf
Shanghai SPRING has supported a wide range of Screen Printing areas such as Solar Cells and Touch Panel Displays. We continue to provide cutting-edge Screen Printing Technology information all over world, Cooperating with many company that produce Photovolta - PV and solar cells, PCB etc electronics manufacturers.
Shanghai SPRING technical experts can suggest changes to further improve the Printed Results with your strong support.
Specifications details:
1. Weave type: Plain or Twill weave, most of customers use PLAIN weave mesh.
2. Mesh count: 7T~200T mesh/cm (18mesh/inch to 500mesh/inch)
3. Characteristics: Good stability and finer printing effect
4. Used: Screen printing and filter
Features & advantages:
1. Hard wear
2. Long working life
3. Even opening and Standard size
4. High tension and Low elongation
5. Acid resistance and Alkali resistance
6. Faster turnaround time from the screen room to the pressroom
7.Unsurpassed UV-light undercutting protection of yellow mesh
8.Adhesion and preparation optimized mesh surface
9.Reproducible mesh relaxation
10.Good ink and paste release behaviour
11.Good antistatic behavior thanks to SPRING antistatic treatment
12.Wide standard range with high availability.
13.Faster tension without damage to the threads
14. Improved fabric strength
15. Faster tension stabilization
16. Higher tension threshold and breaking point
17. Less tension loss during the stretching process
18. Improved registration due to stable tension
19 Faster Print Speeds
Application | undertake printing goods | Plastics | Packaging products, containers, toys, bags, plastic bags, signs |
Metal | Signs, operation panel, dashboard, components | ||
Paper | Advertising, trademarks, wallpaper | ||
wooden product | Signs, sporting goods, lacquer wooden crafts | ||
Glass | All kinds of molded products, bottles, cups | ||
Application industry | Printing and dyeing | Knitwear, textiles, clothing, flags, backpacks, boxes | |
Electronics | Printed circuit boards, thick-film printing | ||
Industrial art | Silk screen prints, celebrities Crafts, oil paintings | ||
Commercial decoration | Household appliances, household hardware | ||
Ceramic | Decals, direct decoration | ||
Publishing and printing | Braille books, books cover | ||
achitechive | All kinds of wallpaper, murals |
The application of various specifications of the screen
Garment printing:
Glitter 25–60 ; Flock adhesive 45–125
Puff-up colors 55–125 ;Overprint 80 –110
Pigment ink printing,areas/lines 110 –175
Plastisol transfer 125–305
Universal fabric 125 ;Plastisol direct 125–305
Pigment inks, half-tone 155–255 ;
Sublimation transfer 195–305
Ceramics:
Glaze printing, coarse, embossed effect 15–55
Glaze printing, medium to fine 55–155
In and under-glaze (direct printing) 110–255
Printed circuit boards:
Overlay solder mask 30 –45
Graphic Screen Printing:
(Glass Containers, Labels,Large Format UV Graphic, Small Format UV Graphic, Solvent Graphics, Tubes and Cartridges),
Line artwork 230 –305 , Halftone screens up to 70 lines/in. 305–380
Halftone screens from 70-133 lines/in. 380 –420 ,Objects (plastics, etc.)
Opaque areas 255–305 ,Halftone and fine lines 305–420
Textiles, flat films:
Heavy décor fabrics (terry cloth, denim) 45–123 ,Smooth, dense fabrics (table cloths, curtains) 110–155
Light, porous material 195–305
Decals:
Areas/lines 195–380 ,Fine lines/half-tone 255–420 ,Gold and luster inks 305–420
Glass -Automotive glass:
Black surrounds for rear/side windows 125–195 ,Antennas 195–255
Silver paste (defroster) 195–255 ,Architectural glass,Windows, doors 55–195 ,Mirrors 195–305
Cosmetic bottles:
Inks 195–305 ,Precious metals 305–380
Beverage:
Bottles, glasses 125–305
Household:
Ovens, etc. (masks) 110 –175 ,Ovens, etc. (lines and half-tones) 195–255 ,Lampshades, furniture 125–255
Advertising:
Shop signs 110 –195, Photosensitive solder mask 60 –175
Membrane keypads and overlays:
Insulation lacquer 90 –175 , Silver conductive paste 125–175 , Adhesive 125–195 , Transparent windows 305
The quality of our products comes from the following aspects:
1.Material:We use two kinds of raw materials, one is the high quality raw materials --jintong wire, one is the import of high-quality Japanese wire.
2.Equipment:Our equipment in 3 years ago were all updated, the new production line put into operation, after nearly six months of repeated debugging, accurate calibration, stable operation, the quality of the finished production of effective control and protection, and into the market, customers get a good feedback.
3.Technical worker:Our technical workers are after strict operation and training, after passing the examination of practice, go to work, the operation technology is mature and stable, so as to ensure the quality of products. And constantly on new technology, new technology to learn, to enhance the skills of skilled workers.
4.Operating technology: our operating technology is based on the performance parameters of the new equipment, and the different materials used, after the guidance of experts in the wire mesh industry, and through the actual production inspection and adjustment and development.
5.Working environment: clean, neat and orderly work environment, is the factory should give a comfortable production staff work places, so as to ensure that employees feel comfortable, but also to ensure the efficient working condition and rigorous work habits, and ultimately ensure the quality of the products.
Quality Control
· Mesh Count inspect
· Thickness inspect
· Thread diameter& Hole size inspect
· Tensile Strength inspect
· Surface Tension test
· Dedicated and experienced weavers
· Consistent quality products
· On-time delivery.Timely tracking of goods, and timely delivery of information to customers· We have 10 R&D technical staffs,with more than 18 years experience
· 86% repeat customers
· Improve after-sales service.
We buy yarn from Jintong, Japan and Switzerland, we inspect the yarn when they unloaded in our factory. (tolerance, tensile strength, physics test etc.).After that, we put the warp wire on beam, draw the warp wire into heddle and reed. Then our experienced weaver will start weaving according to orders.
Initial survey will be done after weaving.Then start heat setting treatment and physical properties inspection, before we get tentative finished rolls(30-500 meters big rolls).In the end, we’ll cut the small rolls(20m-50m) according to customer orders after a final inspection.
high tension polyester silk screen mesh fabric for printing/screen printing mesh
SPRING screen printing mesh is a kind of high-precision product, takes polyester filament as raw material, is made with plain weave or balanced twill weave, and features tensile force and low stretch-back rate. It is widely used in T-shirt,textile,ceramics,paper, electronics, graphics,glass,plastic and packaging, sign and label printing,and other industrial printing tasks.Thanks to its specialty, complete specifications and stable quality, SPRING silk screen mesh have the long-term trust and popularity from domestic and foreign consumers.
Material selection is the first working procedure for production, which is an important function of product quality. In order to ensure good quality, we give priority to material selection. It has not only introduced Japanese polyester filament, but also established a close and friendly cooperative relationship with domestic excellent polyester filament manufacturers. Meanwhile, in terms of every working procedure in production, The company arranges the person responsible, establishes the individual responsibility mechanism.every batch of products must pass strict tests before they are packed and stored. we have seven workshops: warping workshop, dragging and reeding workshop, inspection workshop, cleaning workshop, molding workshop and rolling workshop. every workshop complies with rigorous quality control and standard operation process; we seek greater perfection in every detail, strive to promote product competitiveness, and truly be responsible for every product and every customer.We adhere to the "integrity, innovation, responsibility" concept to provide customers with high quality products, perfect service. We have won favorable comments from old and new customers. We are glad to establish good relationship with more and more customers from all over the world.
Product data:
Our certification:
high tension polyester silk screen mesh fabric for printing/screen printing mesh
Polyester Monofilament Mesh | ||||||
Type |
Mesh Count (/cm) |
Mesh Count (/inch) |
Thread Diameter (/um) |
Mesh Opening (um) |
Open Area (%) |
Thickness (um) |
DPP 7 | 7T | 18 | 350 | 1079 | 57 | 640 |
DPP 8 | 8T | 20 | 300 | 950 | 58 | 550 |
DPP 10 | 10T | 25 | 250 | 750 | 56 | 445 |
DPP 12 | 12T | 30 | 250 | 583 | 49 | 450 |
DPP 16 | 16T | 40 | 200 | 425 | 46 | 400 |
DPP 20 | 20S | 50 | 100 | 400 | 64 | 200 |
DPP 20 | 20T | 50 | 150 | 350 | 49 | 260 |
DPP 20 | 20HD | 50 | 180 | 320 | 41 | 338 |
DPP 24 | 24S | 60 | 100 | 317 | 58 | 190 |
DPP 24 | 24T | 60 | 120 | 297 | 51 | 220 |
DPP 27 | 27T | 70 | 70 | 300 | 66 | 125 |
DPP 32 | 32S | 80 | 80 | 233 | 55 | 140 |
DPP 32 | 32T | 80 | 100 | 213 | 46 | 170 |
DPP 34 | 34T | 86 | 100 | 194 | 44 | 170 |
DPP 36 | 36S | 90 | 80 | 198 | 51 | 137 |
DPP 36 | 36T | 90 | 100 | 178 | 41 | 198 |
DPP 39 | 39S | 100 | 55 | 201 | 62 | 95 |
DPP 39 | 39T | 100 | 80 | 176 | 47 | 141 |
DPP 39 | 39HD | 100 | 100 | 156 | 37 | 185 |
DPP 43 | 43T | 110 | 80 | 153 | 43 | 132 |
DPP 47 | 47S | 120 | 55 | 158 | 55 | 95 |
DPP 47 | 47T | 120 | 71 | 142 | 44 | 135 |
DPP 53 | 53S | 135 | 55 | 134 | 50 | 95 |
DPP 53 | 53T | 135 | 64 | 125 | 44 | 118 |
DPP 53 | 53HD | 135 | 71 | 118 | 39 | 130 |
DPP 59 | 59S | 150 | 55 | 114 | 46 | 88 |
DPP 59 | 59T | 150 | 64 | 105 | 39 | 105 |
DPP 61 | 61T | 155 | 55 | 109 | 44 | 84 |
DPP 62 | 62T | 155 | 64 | 97 | 36 | 97 |
DPP 64 | 64S | 163 | 55 | 101 | 42 | 85 |
DPP 64 | 64T | 163 | 64 | 92 | 35 | 100 |
DPP 68 | 68S | 173 | 55 | 92 | 39 | 85 |
DPP 68 | 68T | 173 | 64 | 83 | 32 | 100 |
DPP 72 | 72S | 183 | 48 | 91 | 43 | 89 |
DPP 72 | 72T | 183 | 55 | 84 | 36 | 100 |
DPP 77 | 77T | 195 | 55 | 75 | 33 | 86 |
DPP 80 | 80T | 200 | 48 | 77 | 38 | 76 |
DPP 90 | 90S | 230 | 45 | 66 | 35 | 69 |
DPP 90 | 90T | 230 | 48 | 63 | 32 | 76 |
DPP 100 | 100T | 250 | 40 | 60 | 36 | 61 |
DPP 110 | 110T | 280 | 40 | 51 | 31 | 58 |
DPP 120 | 120S | 300 | 31 | 52 | 39 | 53 |
DPP 120 | 120T | 300 | 34 | 49 | 35 | 58 |
DPP 120 | 120HD | 300 | 40 | 43 | 27 | 65 |
DPP 140 | 140S | 350 | 31 | 40 | 32 | 49 |
DPP 140 | 140T | 350 | 34 | 37 | 27 | 59 |
DPP 150 | 150S | 380 | 31 | 36 | 29 | 52 |
DPP 150 | 150T | 380 | 34 | 33 | 24 | 60 |
DPP 165 | 165S | 420 | 27 | 34 | 31 | 44 |
DPP 165 | 165T | 420 | 31 | 30 | 24 | 53 |
DPP 180 | 180T | 460 | 27 | 29 | 26 | 42 |
DPP 200 | 200T | 500 | 27 | 23 | 21 | 45 |
Remark: These are theoretical data for reference only. Mesh Opening & Open Area only slight error according to actual data. |
